2002 Fairchild Semiconductor Corporation
Rev. A1, April 2002
F
QF E T
TM
FQG4902
250V Dual N & P-Channel MOSFET
General Description
These dual N and P-channel enhancement mode power
field effect transistors are produced using Fairchild’s
proprietary, planar stripe, DMOS technology.
This advanced technology has been especially tailored to
minimize on-state resistance, provide superior switching
performance, and withstand high energy pulse in the
avalanche and commutation mode. These devices are well
suited for electronic lamp ballast based on half bridge.
Features
N-Channel 0.54A, 250V, R
DS(on)
= 2.0
@ V
GS
= 10 V
P-Channel -0.54A, -250V, R
DS(on)
= 2.0
@ V
GS
= -10 V
Low gate charge ( typical N-Channel 6.0 nC)
( typical P-Channel 12.0 nC)
Fast switching
Improved dv/dt capability
Absolute Maximum Ratings
T
A
= 25°C unless otherwise noted
Thermal Characteristics
Symbol
V
DSS
I
D
Parameter
N-Channel
250
0.54
0.34
4.32
P-Channel
-250
-0.54
-0.34
-4.32
Units
V
A
A
A
V
V/ns
W
W/°C
°C
Drain-Source Voltage
Drain Current
- Continuous (T
A
= 25°C)
- Continuous (T
A
= 100°C)
- Pulsed
I
DM
V
GSS
dv/dt
P
D
Drain Curent
Gate-Source Voltage
Peak Diode Recovery dv/dt
Power Dissipation (T
A
= 25°C)
Operating and Storage Temperature Range
(Note 1)
±
30
(Note 2)
5.5
-5.5
1.4
0.011
- Derate above 25°C
T
J
, T
STG
-55 to +150
Symbol
R
θ
JA
Parameter
Typ
--
Max
90
Units
°C
/
W
Thermal Resistance, Junction-to-Ambient
(Note 5a)
S1
G1
S2
G2
D1
D1
D2
D2
Pin #1
4
3
2
1
5
6
7
8
8-DIP
