I5216 SERIES
Advanced Information
PRELIMINARY
Publication Release Date: November 30, 2001
-8
Revision A1
FUNCTIONAL DESCRIPTION
The I5216 ChipCorder
Product provides high quality, fully integrated, single-chip Record/Playback
solutions for 8- to 16-minute messaging applications that are ideal for use in PBX systems, cellular
phones, automotive communications, GPS/navigation systems, and other portable products. The I5216
product is an enhancement to the ISD5116 architecture, providing: 1) A full duplex Voice CODEC with
μ
-Law and A-Law compander, with I
2
S and PCM interface ports; 2) A 2.2V microphone bias supply for
reduced noise coupling. This supply can also be used to power down the external microphone with the
system.
Analog functions and audio gating have also been integrated into the I5216 product to allow for easy
interfacing with integrated chip sets on the market. Audio paths have been designed to enable full
duplex conversation record, voice memo and answering machine (including outgoing message
playback).
Logic Interface Options of 2.0V and 3.0V are supported by the I5216 to accommodate both portable
communication (2.0- and 3.0-volt required) and automotive product customers (5.0-volt required).
Like other ChipCorder
products, the I5216 integrates the sampling clock, anti-aliasing and smoothing
filters, and multi-level storage array on a single chip. For enhanced voice features, the I5216 eliminates
external circuitry by integrating automatic gain control (AGC), a power amplifier/speaker driver, volume
control, summing amplifiers, analog switches, and a Voice CODEC. Input level adjustable amplifiers
are also included, providing a flexible interface for multiple applications.
Recordings are stored in on-chip nonvolatile memory cells, providing zero-power message storage.
This unique, single-chip solution is made possible through Winbond’s patented multilevel storage
technology. Voice and audio signals are stored directly into solid-state memory in their natural,
uncompressed form, providing superior quality voice and music reproduction.
SPEECH/SOUND QUALITY
The I5216 ChipCorder product can be configured, via software, to operate at 4.0, 5.3, 6.4, and 8.0 kHz
sampling frequencies, allowing the user a choice of speech quality options. Increasing the duration
decreases the sampling frequency and bandwidth, which affects sound quality. The "
Input Sample
Duration
" table below compares filter pass band and product durations.
DURATION
To meet end-system requirements, the I5216 device is a single-chip solution, which provides 8 to 16
minutes of voice record and playback, depending on the sample rates defined by the customer's
software.
INPUT SAMPLE RATE TO DURATION INPUT SAMPLE
Rate (kHz)
Duration
1
(Minutes)
Typical Filter Pass Band (kHz)
8.0
8 min 3 sec
3.7
6.4
10 min 4 sec
2.9
5.3
12 min 9 sec
2.5
4.0
16 min 6 sec
1.8
1. Minus any pages selected for digital storage
