Philips Semiconductors
ISP1181A
Full-speed USB peripheral controller
Product data
Rev. 05 — 08 December 2004
35 of 70
9397 750 13959
Koninklijke Philips Electronics N.V. 2004. All rights reserved.
12.2.4
Validate Endpoint Buffer
This command signals the presence of valid data for transmission to the USB host, by
setting the Buffer Full flag of the selected IN endpoint. This indicates that the data in
the buffer is valid and can be sent to the host, when the next IN token is received. For
a double-buffered endpoint this command switches the current FIFO for CPU access.
Remark:
For special aspects of the control IN endpoint see
Section 9.5
.
Code (Hex): 61 to 6F —
validate endpoint buffer (control IN, endpoint 1 to 14)
Transaction —
none
12.2.5
Clear Endpoint Buffer
This command unlocks and clears the buffer of the selected OUT endpoint, allowing
the reception of new packets. Reception of a complete packet causes the Buffer Full
flag of an OUT endpoint to be set. Any subsequent packets are refused by returning a
NAK condition, until the buffer is unlocked using this command. For a double-buffered
endpoint this command switches the current FIFO for CPU access.
Remark:
For special aspects of the control OUT endpoint see
Section 9.5
.
Code (Hex): 70, 72 to 7F —
clear endpoint buffer (control OUT, endpoint 1 to 14)
Transaction —
none
12.2.6
Check Endpoint Status
This command is used to check the status of the selected endpoint FIFO without
clearing any status or interrupt bits. The command accesses the Endpoint Status
Image Register, which contains a copy of the Endpoint Status Register. The bit
allocation of the Endpoint Status Image Register is shown in
Table 33
.
Code (Hex): D0 to DF —
check status (control OUT, control IN, endpoint 1 to 14)
Transaction —
write/read 1 byte
Table 33:
Bit
Symbol
Endpoint Status Image Register: bit allocation
7
6
EPSTAL
EPFULL1
5
4
3
2
1
0
EPFULL0
DATA_PID
OVER
WRITE
0
R
SETUPT
CPUBUF
reserved
Reset
Access
0
R
0
R
0
R
0
R
0
R
0
R
0
R
Table 34:
Bit
7
Endpoint Status Image Register: bit description
Symbol
Description
EPSTAL
This bit indicates whether the endpoint is stalled or not
(1 = stalled, 0 = not stalled).
EPFULL1
A logic 1 indicates that the secondary endpoint buffer is full.
EPFULL0
A logic 1 indicates that the primary endpoint buffer is full.
DATA_PID
This bit indicates the data PID of the next packet
(0 = DATA0 PID, 1 = DATA1 PID).
6
5
4
