LC82161B-E
No.7775-7/19
Continued from preceding page.
Pin No.
Pin name
I/O
Pin type
Function
158
D29
B
3IC/3T4
159
D28
B
3IC/3T4
160
D27
B
3IC/3T4
161
D26
B
3IC/3T4
162
D25
B
3IC/3T4
163
D24
B
3IC/3T4
164
D23
B
3IC/3T4
165
D22
B
3IC/3T4
166
D21
B
3IC/3T4
167
D20
B
3IC/3T4
168
D19
B
3IC/3T4
169
D18
B
3IC/3T4
170
D17
B
3IC/3T4
171
D16
B
3IC/3T4
Data bus
172
DVDD3
P
Digital system power supply (+3.3 V)
173
DGND
P
Digital system ground
174
D15
B
3IC/3T4
175
D14
B
3IC/3T4
176
D13
B
3IC/3T4
177
D12
B
3IC/3T4
178
D11
B
3IC/3T4
179
D10
B
3IC/3T4
180
D9
B
3IC/3T4
181
D8
B
3IC/3T4
182
D7
B
3IC/3T4
183
D6
B
3IC/3T4
184
D5
B
3IC/3T4
185
D4
B
3IC/3T4
186
D3
B
3IC/3T4
187
D2
B
3IC/3T4
188
D1
B
3IC/3T4
189
D0
B
3IC/3T4
Data bus
190
DVDD2
P
Digital system power supply (+2.5 V)
191
DGND
P
Digital system ground
192
CTSn1/PC4
B
3IC/3T4
USART1 clear to send signal or I/O port
193
DSRn1/PC5
B
3IC/3T4
USART1 dataset ready signal or I/O port
194
RTSn1/PC11
B
3IC/3T4
USART1 request to send signal or I/O port
195
DTRn1/PC12
B
3IC/3T4
USART1 data terminal ready signal or I/O port
196
EXCK1/PC6
B
3IC/3T4
USART1 external clock input or I/O port
197
TXD1/PC13
B
3IC/3T4
USART1 serial data output or I/O port
198
RXD1/PC7
B
3IC/3T4
USART1 serial data input or I/O port
199
A24
O
3O4
200
A23
O
3O4
201
A22
O
3O4
202
A21
O
3O4
203
A20
O
3O4
204
A19
O
3O4
205
A18
O
3O4
206
A17
O
3O4
207
A16
O
3O4
Address bus
208
DVDD3
P
Digital system power supply (+3.3 V)
