參數資料
型號: MAX5978ETJ+
廠商: Maxim Integrated
文件頁數: 22/38頁
文件大小: 2412K
描述: IC CTLR HOT-SWAP 32TQFN
產品培訓模塊: Lead (SnPb) Finish for COTS
Obsolescence Mitigation Program
標準包裝: 1
類型: 熱交換控制器
應用: 刀峰式服務器,網絡應用設備
內部開關:
電流限制: 可調
電源電壓: 2.7 V ~ 16 V
工作溫度: -40°C ~ 85°C
安裝類型: 表面貼裝
封裝/外殼: 32-WFQFN 裸露焊盤
供應商設備封裝: 32-TQFN-EP(5x5)
包裝: 管件
0 to 16V, Hot-Swap Controller with 10-Bit
Current, Voltage Monitor, and 4 LED Drivers
22
Digital Voltage Monitoring and Power-Good
Output
The voltage at the load (MON input) is sampled by the
internal ADC. The MON full-scale voltage can be set to
16V, 8V, 4V, or 2V by writing to register mon_range. The
default range is 16V (Tables 16 and 17).
The most recent voltage-conversion results can be read
from the adc_mon_msb and adc_mon_lsb registers (see
Tables 18 and 19).
Digital Undervoltage- and Overvoltage-
Detection Thresholds
The most recent voltage values are continuously com-
pared to four programmable limits, comprising two
undervoltage (UV) levels (see Tables 20 to 23) and two
overvoltage (OV) levels (see Tables 24 to 27).
If PG is asserted and the voltage is outside the warning
limits, the ALERT output is asserted low. Depending on
the status of the prot[] bits in register status1[7:6], the
Table 16. ADC Voltage Monitor Settings Register Format
Table 17. ADC Full-Scale Voltage Setting
Table 18. ADC Voltage-Conversion Result Register Format (High-Order Bits)
Table 19. ADC Voltage-Conversion Result Register Format (Low-Order Bits)
Description:
ADC voltage monitor full-scale range settings (for MON input)
Register Title:
mon_range
Register Addresses:
0x18
RESET
VALUE
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W




Unused
Unused
MON_rng1
MON_rng0
0x00
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0

MON_rng1
MON_rng0
ADC FULL-SCALE VOLTAGE (V)
0
0
16
0
1
8
1
0
4
1
1
2
Description:
Most recent voltage-conversion result, high-order bits [9:2]
Register Title:
adc_mon_msb
Register Addresses:
0x02
RESET
VALUE
R
R
R
R
R
R
R
R
vnew_9
vnew_8
vnew_7
vnew_6
vnew_5
vnew_4
vnew_3
vnew_2
0x00
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0

Description:
Most recent voltage-conversion result, low-order bits [1:0]
Register Title:
adc_mon_lsb
Register Addresses:
0x03
RESET
VALUE
R
R
R
R
R
R
R
R






vnew_1
vnew_0
0x00
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
