0 to 16V, Hot-Swap Controller with 10-Bit
Current, Voltage Monitor, and 4 LED Drivers
30
Force-On Function
When the force-on bit is set to 1 in register foset[0] (see
Table 44), the channel is enabled regardless of the ON
pin voltage or the EN1 and EN2 bits in register chxen. In
forced-on operation, all functions operate normally with
the notable exception that the channel does not shut
down due to any fault conditions that may arise.
There is a force-on key register fokey that must be set to
0xA5 in order for the force-on function to become active
(see Table 45). If this register contains any value other
than 0xA5, writing 1 to the force-on bits in register foset
has no effect. This provides protection against acciden-
tal force-on operation that might otherwise be caused by
an erroneous I
2
C write.
Fault Logging and Indications
The device provides detailed information about any fault
conditions that have occurred. The FAULT output spe-
cifically indicates a circuit-breaker shutdown event, while
the ALERT output is asserted whenever a problem has
occurred that requires attention or interaction.
Table 43. Circular Buffer Stop-Delay Register Format
Table 44. Force-On Control Register Format
Table 45. Force-On Key Register Format
Description:
Circular buffer stop delay: any integer number between 0 and 50 samples that are to be recorded to a
buffer after a shutdown event, before the buffer stops storing new data
Register Title:
cbuf_dly_stop
Register Address:
0x40
RESET
VALUE
R
R
R/W
R/W
R/W
R/W
R/W
R/W
0
0
Stop_dly[5]
Stop_dly[4]
Stop_dly[3]
Stop_dly[2]
Stop_dly[1]
Stop_dly[0]
0x19
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Description:
Force-on control register
Register Title:
foset
Register Address:
0x3A
RESET
VALUE
R
R
R
R
R
R
R/W
R/W
0
0
0
0
0
0
Unused
fo
0x00
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Description:
Force-on key register (must contain 0xA5 to unlock force-on feature)
Register Title:
fokey
Register Address:
0x39
RESET
VALUE
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
fokey[7]
fokey[6]
fokey[5]
fokey[4]
fokey[3]
fokey[2]
fokey[1]
fokey[0]
0x00
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
