參數資料
| 型號： | MAX9737EVKIT+ |
| 廠商： | Maxim Integrated Products |
| 文件頁數： | 6/13頁 |
| 文件大小： | 0K |
| 描述： | KIT EVAL FOR MAX9737 |
| 產品培訓模塊： | Lead (SnPb) Finish for COTS Obsolescence Mitigation Program |
| 標準包裝： | 1 |
| 放大器類型： | D 類 |
| 輸出類型： | 1-通道（單聲道） |
| 在某負載時最大輸出功率 x 通道數量： | 13W x 1 @ 4 歐姆 |
| 電源電壓： | 8 V ~ 28 V |
| 工作溫度： | -40°C ~ 85°C |
| 板類型： | 完全填充 |
| 已用 IC / 零件： | MAX9737 |
| 已供物品： | 板 |
MAX9737
Mono 7W Class D Amplifier
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS
(VPVDD = 12V, VAGND = VPGND = 0, VSHDN = VMUTE = 5V, C1 = 0.1F, CIN = 0.47F, C2 = CCOM = CREG = 1F, RIN = RFB = 20k
Ω,
RL =
∞, AC measurement bandwidth 22Hz to 22kHz, TA = TMIN to TMAX, unless otherwise noted. Typical values are at TA = +25°C.)
(Note 3)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
PVDD to PGND.......................................................-0.3V to +30V
AGND to PGND .....................................................-0.3V to +0.3V
IN, PRE, PC, COM to AGND.....................-0.3V to (VREG + 0.3V)
MUTE, SHDN to AGND ............................................-0.3V to +6V
REG to AGND ...............................................-0.3V to (VS + 0.3V)
VS to AGND ..............................................................-0.3V to +6V
OUT+, OUT- to PGND .............................-0.3V to (PVDD + 0.3V)
C1N to PGND ..........................................-0.3V to (PVDD + 0.3V)
C1P to PGND .........................(PVDD - 0.3V) to (VCHOLD + 0.3V)
CHOLD to PGND .......................................(VC1P - 0.3V) to +36V
OUT+, OUT-, Short Circuit to PGND or PVDD ...........Continuous
Thermal Limits (Notes 1, 2)
Continuous Power Dissipation (TA = +70°C)
24-Pin TQFN Single-Layer PCB (derate 20.8mW/°C
above +70°C)........................................................1666.7mW
θJA................................................................................48°C/W
θJC..................................................................................3°C/W
Continuous Power Dissipation
24-Pin TQFN Multiple-Layer PCB
(derate 27.8mW/°C above +70°C) ........................2222.2mW
θJA................................................................................36°C/W
θJC..................................................................................3°C/W
Operating Temperature Range ...........................-40°C to +85°C
Storage Temperature Range .............................-65°C to +150°C
Junction Temperature ......................................................+150°C
Lead Temperature (soldering, 10s) .................................+300°C
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
AMPLIFIER DC CHARACTERISTICS
Speaker-Supply Voltage Range
PVDD
Inferred from PSRR test
8
28
V
Undervoltage Lockout
UVLO
6.8
V
TA = +25°C
15
20
Quiescent Supply Current
IPVDD
25
mA
Shutdown Supply Current
ISHDN
VSHDN = 0, TA = +25°C
1
10
A
REG Voltage
VREG
4.0
4.2
4.5
V
Preregulator Voltage
VS
4.85
V
COM Voltage
VCOM
1.94
2.06
2.16
V
INPUT AMPLIFIER CHARACTERISTICS
Capacitive Drive
CL
No sustained oscillation
30
pF
Output Swing
Sinking ±1mA (Note 4)
2.05
V
Open-Loop Gain
AVO
88
dB
Input Offset Voltage
VOS
IN to COM
±2
mV
Input Amplifier Slew Rate
2.5
V/s
Input Amplifier Unity-Gain
Bandwidth
3.5
MHz
Note 1: Thermal performance of this device is highly dependent on PCB layout. See the
Applications Information section for more detail.
Note 2: Package thermal resistances were obtained using the method described in JEDEC specification JESD51-7, using a four-layer
board. For detailed information on package thermal considerations, refer to www.maxim-ic.com/thermal-tutorial.
