FUNCTIONAL DESCRIPTION (continued)
MODE REGISTER SET (MRS)
The mode register of SDRAM provides a variety of different operations. The register consists of four operation fields;
Burst Length, Burst Type, CAS Latency, and Test Mode Entry (This Test Mode Entry must not be used.)
Refer to MODE REGISTER TABLE in page 25.
The mode register can be programmed by the Mode Register Set command (MRS). Each field is set by the address
line. Once a mode register is programmed, the contents of the register will be held until re-programmed by another
MRS command (or part loses power). MRS command should only be issued on condition that all banks are in idle
state and all DQS are in High-Z. The condition of the mode register is undefined after the power-up stage. It is
required to set each field at power-up initialization.
Refer to POWER-UP INITIALIZATION below.
Note:
The Extended Mode Register Set command (EMRS) and its DLL Enable function of EMRS field is only
used at power-on sequence.
POWER-UP INITIALIZATION
The MB81N643289 internal condition at and after power-up will be undefined. Since MB81N643289 adopts the
method for two power supplies, which has two different power supply pins for internal core and I/O, it is required to
follow the following Power On Sequence to execute read or write operation.
1.
Apply V
DD
voltage to all V
DD
pins before or at the same time as V
DDQ
pins and attempt to maintain all input
signals to be Low state (or at least PD to be Low state).
2.
Apply V
DD
voltage to all V
DDQ
pins before or at the same time as V
REF
.
3.
Apply V
REF
.
4.
Start clock after all power supplies reached in a specified operating range and maintain stable condition
for a minimum of 200
μ
s.
5.
After the minimum of 200
μ
s stable power and clock, apply NOP condition and take PD to be High state.
6.
Issue Page Close All Banks (PCA) command or Page Close Single Bank (PC) command to every banks.
7.
Issue EMRS to enable DLL, DE = Low.
8.
Issue Mode Register Set command (MRS) to reset DLL, DR = High. An additional clock input for l
LOCK
*
1
period is required to lock the DLL.
9.
Apply minimum of two Auto-refresh command (REF).*
2
10. Program the mode register by Mode Register Set command (MRS) with DR = Low.*
2
Notes: *1. The l
LOCK
depends on operating clock period. The l
LOCK
is counted from “DLL Reset” at step-8 to any
command input at step-10.
*2. The Mode Register Set command (MRS) can be issued before two Auto-refresh cycle (REF).
POWER-DOWN
The MB81N643289 uses multiple power supply voltage. It is required to follow the reversed sequence of above
Power On Sequence.
1.
Take all input signals to be V
SS
or High-Z.
2.
Deapply V
DDQ
.
3.
Deapply V
DD
after or at the same time as V
DDQ
.
