MCM64PC32T
MCM64PC64T
5
MOTOROLA FAST SRAM
PIN DESCRIPTIONS
160–Lead Card Edge Pin Locations
Symbol
Type
Description
20, 21, 22, 23, 24, 26, 28, 29,
101, 102, 103, 104, 106, 108, 109, 110
A3 – A18
Input
Address Inputs: These inputs are registered into data RAMs and must
meet setup and hold times. The tag RAM addresses are not registered.
30
ADSP
Input
Address Status Processor: Initiates READ, WRITE, or chip deselect
cycle (Exception–chip deselect does not occur when ADSP is asserted
and CCS is high.
114
BOSEL
Input
Burst Order Select: NC for interleaved burst counter. Tie to ground for
linear burst counter.
18
BWE
Input
Byte Write Enable: To be used in future modules.
9
CADS
Input
Cache Address Status: Initiates READ, WRITE, or chip deselect cycle.
89
CADV
Input
Cache Burst Advance: Increments address count in accordance with
interleaved count style.
16
CCS
Input
Chip Select: Active low chip enable for data RAMs.
91
CG
Input
Cache Output Enable: Active low asynchronous input.
Low–enables output buffers (DQ pins)
High–DQx pins are high impedance.
36, 116
CLK0,
CLK1
Input
Clock: This signal registers the address, data in, and all control signals
except CG.
11, 12, 13, 14, 92, 93, 94, 96
CWE0 –
CWE7
Input
Cache Data Byte Write Enable: Active low write signal for data RAMs.
38, 40, 41, 42, 44, 45, 46, 47, 49, 50, 51,
53, 54, 55, 57, 58, 59, 61, 62, 63, 65, 66,
67, 69, 70, 71, 73, 74, 75, 77, 78, 79,
118, 120, 121, 122, 124, 125, 126, 127,
129, 130, 131, 133, 134, 135, 137, 138,
139, 141, 142, 143, 145, 146, 147, 149,
150, 151, 153, 154, 155, 157, 158, 159
DQ0 –
DQ63
I/O
Synchronous Data I/O:
Drives data out of data RAMs during READ cycles.
Stores data to data RAMs during WRITE cycles.
31, 32
ECS1,
ECS2
Input
Expansion Chip Select
17
GWE
Input
Global Write Enable: To be used in future modules.
33, 34, 112, 113
PD0 –
PD3
—
Presence Detect: See Presence Detect Table
100, 111
RSVD
—
No Connection: Reserved for future use.
2, 3, 4, 5, 82, 83, 84, 85
TIO0 –
TIO7
I/O
Tag RAM I/O:
Drives data out during tag compare cycles.
Stores data to tag RAM during tag WRITE cycles.
8
TWE
Input
Tag Write Enable: Active low write signal for tag RAMs.
7, 15, 25, 39, 52, 60, 68, 76
VDD3
VDD5
VSS
Supply
Power Supply: 3.3 V + 10%, – 5%.
87, 95, 105, 119, 132, 140, 148, 156
Supply
Power Supply: 5.0 V
±
5%.
1, 10, 19, 27, 35, 37, 43, 48, 56, 64, 72,
80, 81, 90, 99, 107, 115, 117, 123, 128,
136, 144, 152, 160
Supply
Ground
6, 86, 88, 97, 98
NC
—
No Connection: There is no connection to the module.
