1
Motorola Small–Signal Transistors, FETs and Diodes Device Data
PNP Silicon
MAXIMUM RATINGS
Rating
Symbol
Value
Unit
Collector–Emitter Voltage
VCEO
VCBO
VEBO
–20
Vdc
Collector–Base Voltage
–20
Vdc
Emitter–Base Voltage
–3.0
Vdc
DEVICE MARKING
MMBTH81LT1 = 3D
THERMAL CHARACTERISTICS
Characteristic
Symbol
Max
Unit
Total Device Dissipation FR-5 Board,(1)
TA = 25
°
C
Derate above 25
°
C
PD
225
1.8
mW
mW/
°
C
Thermal Resistance, Junction to Ambient
R
θ
JA
PD
556
°
C/W
Total Device Dissipation
Alumina Substrate,(2) TA = 25
°
C
Derate above 25
°
C
300
2.4
mW
mW/
°
C
Thermal Resistance, Junction to Ambient
R
θ
JA
TJ, Tstg
417
°
C/W
Junction and Storage Temperature
–55 to +150
°
C
ELECTRICAL CHARACTERISTICS
(TA = 25
°
C unless otherwise noted)
Characteristic
Symbol
Min
Typ
Max
Unit
OFF CHARACTERISTICS
Collector–Emitter Breakdown Voltage (IC = –1.0 mAdc, IB = 0)
Collector–Base Breakdown Voltage (IC = –10
μ
Adc, IE = 0)
Emitter–Base Breakdown Voltage (IE = –10
μ
Adc, IC = 0)
Collector Cutoff Current (VCB = –10 Vdc, IE = 0)
Emitter Cutoff Current (VEB = –2.0 Vdc, IC = 0)
ON CHARACTERISTICS
V(BR)CEO
V(BR)CBO
V(BR)EBO
ICBO
IEBO
–20
—
—
Vdc
–20
—
—
Vdc
–3.0
—
—
Vdc
—
—
–100
nAdc
—
—
–100
nAdc
DC Current Gain (IC = –5.0 mAdc, VCE = –10 Vdc)
Collector–Emitter Saturation Voltage (IC = –5.0 mAdc, IB = –0.5 mAdc)
Base–Emitter On Voltage (IC = –5.0 mAdc, VCE = –10 Vdc)
SMALL–SIGNAL CHARACTERISTICS
hFE
60
—
—
—
VCE(sat)
VBE(on)
—
—
–0.5
Vdc
—
—
–0.9
Vdc
Current–Gain – Bandwidth Product
(IC = –5.0 mAdc, VCE = –10 Vdc, f = 100 MHz)
fT
600
—
—
MHz
Collector–Base Capacitance (VCB = –10 Vdc, IE = 0, f = 1.0 MHz)
Collector–Emitter Capacitance (IB = 0, VCB = –10 Vdc, f = 1.0 MHz)
Ccb
Cce
—
—
0.85
pF
—
—
0.65
pF
1. FR–5 = 1.0 x 0.75 x 0.062 in.
2. Alumina = 0.4 x 0.3 x 0.024 in. 99.5% alumina.
Thermal Clad is a trademark of the Bergquist Company
Preferred
devices are Motorola recommended choices for future use and best overall value.
Order this document
by MMBTH81LT1/D
SEMICONDUCTOR TECHNICAL DATA
Motorola Preferred Device
1
2
3
CASE 318–08, STYLE 6
SOT–23 (TO–236AB)
COLLECTOR
3
1
BASE
2
EMITTER
