6
RF Device Data
Freescale Semiconductor
MRF284LSR1
Table 5. 2000 MHz Class A Test Circuit Component Designations and Values
Designators
Description
B1 -- B5
Ferrite Beads, Round, Ferroxcube # 56--590--65--3B
C1, C9, C16
100 F, 50 V Electrolytic Capacitors, Mallory #SME50VB101M12X25L
C2, C13
51 pF Chip Capacitors, ATC #100B510JCA500x
C3, C14
10 pF Chip Capacitors, ATC #100B100JCA500X
C4, C11
12 pF Chip Capacitors, ATC #100B120JCA500X
C5
0.8 -- 8.0 pF Variable Capacitor, Johansen Gigatrim #27291SL
C6
4.7 pF Chip Capacitor, ATC #100B4R7CCA500X
C7, C15
91 pF Chip Capacitors, ATC #100B910KP500X
C8
1000 pF Chip Capacitor, ATC #100B102JCA50X
C10
0.1 F Chip Capacitor, Kemet #CDR33BX104AKWS
C12, C17
0.6 -- 4.5 pF Variable Capacitors, Johansen Gigatrim #27271SL
L1
4 Turns, #27 AWG, 0.087″ OD, 0.050″ ID, 0.069″ Long, 10 nH
L2
5 Turns, #24 AWG, 0.083″ OD, 0.040″ ID, 0.128″ Long, 12.5 nH
L3, L4
9 Turns, #26 AWG, 0.080″ OD, 0.046″ ID, 0.170″ Long, 30.8 nH
P1
1000
Potentiometer, 1/2 W, 10 Turns, Bourns
Q1
Transistor, NPN, #MJD31, Case 369A--10
Q2
Transistor, PNP, #MJD32, Case 369A--10
R1
360
, Fixed Film Chip Resistor, 0.08″ x 0.13″, Garrett Instruments #RM73B2B361JT
R2
2 x 12 k , Fixed Film Chip Resistor, 0.08″ x 0.13″, Garrett Instruments #RM73B2B122JT
R3
1
, Wirewound, 5 W, 3% Resistor, Dale # RE60G1R00
R4
4 x 6.8 k , Fixed Film Chip Resistor, 0.08″ x 0.13″, Garrett Instruments #RM73B2B682JT
R5
2 x 1500
, Fixed Film Chip Resistor, 0.08″ x 0.13″, Garrett Instruments #RM73B2B152JT
R6
270
, Fixed Film Chip Resistor, 0.08″ x 0.13″, Garrett Instruments #RM73B2B271JT
R7 -- R11
12
, Fixed Film Chip Resistors, 0.08″ x 0.13″, Garrett Instruments #RM73B2B120JT
