Hi-Rel PREGULATOR MODULE
PGDS-50 : up to 50W POWER
Transient suppressor module 80V
MIL-STD-704A/D/E/F, EN2282, AIR2021E
DO160D cat A, B and Z
Transient suppressor module 100V
MIL-STD-1275A/B,
Spike suppressor module 600V
MIL-STD-704A/D/E/F, EN2282, AIR2021E
DO160D cat A, B and Z
Extended operation for voltage drop out
and cranking down to 6V
Power range : from 4W to 50W
Inhibition function
RoHS or Leaded process
Gaia Converter FC97-012.01/10 Revision J
REDEFINING THE SOURCE OF POWER
1- General
Hi-Rel
Grade
For locations, phone, fax, E-Mail see back cover
2- Product Selection
Input Voltage Range
K
Output
The GAIA Converter pre-regulator PGDS-50 series
designates a low profile power adaptator mo-
dule designed to extend input bus voltage to
meet system operation during voltage transients,
spikes, cranking and drop out occuring in avionics
or military systems.
The PGDS-50 delivers an output voltage adapted
to GAIA Converter DC/DC modules. This line of
module is optimized to provide high power
efficiency up to 96% over the whole power range
between 4W and 50W.
The PGDS-50 features 4 modes of operations as
follow:
Low line operation :
Low line operation occurs when the input
bus voltage drops down below the perma-
nent input voltage range of the DC/DC
converter ; then the PGDS-50 operates in
boost mode to provide an output voltage
compatible with DC/DC converter.
The PGDS-50 series can sustain low line
operation down to 6V.
Power fail operation :
An undervoltage lock-out stops operation and
disables the boost mode for voltage below
Brown-out - Transient
N : 10V/15s - 80V/100ms
O : 6V/1s - 100V/50ms
this low line operation.
Normal operation :
Normal operation occurs between the per-
manent input voltage of DC/DC converter;
The module is then operating in steady
transparency state.
Transient and spike operation :
The PGDS-50 can sustain input transient up
to 80V/100ms or 100V/50ms and spike up to
600V during 20s with 50 ohms impedance .
The PGDS-50 series is compliant with the inter-
national input bus standards :
- MIL-STD-704A/D/E/F
- AECMA EN2282
- GAM-EG13B/AIR2021E
- DO160D cat A, B and Z
- MIL-STD-1275A/B
The design has been carried out with
surface mount components and is manufactured
in a fully automated process to guarranty high
quality. Every module is tested with a Gaa
Converter automated test equipment. The mo-
dules are potted with a bi-component thermal
conductive compound and packaged in a metallic
case to ensure the module’s integrity under high
environmental conditions.
4
10-80V or 6-100V Brown-out / Transient
600V Spike Suppression Module
Metallic Case
Options :
Suffix :
/T : option for -55°C start up operating temperature
nothing : RoHS process
/S : option for screening and serialization
-L : leaded process (available in US)
PGDS - 50 -
option
/
suffix
input
output
