| 型號： | QEB373 |
| 廠商： | FAIRCHILD SEMICONDUCTOR CORP |
| 元件分類： | 紅外LED |
| 英文描述： | SUBMINIATURE PLASTIC INFRARED EMITTING DIODE |
| 中文描述： | 2 mm, 1 ELEMENT, INFRARED LED, 880 nm |
| 封裝： | PLASTIC PACKAGE-2 |
| 文件頁數： | 1/4頁 |
| 文件大小： | 130K |
| 代理商： | QEB373 |
1 of
4
100008A
NOTES
1. Derate power dissipation linearly
1.33 mW/°C above 25°C.
2. RMA flux is recommended.
3. Methanol or isopropyl alcohols
are recommended as cleaning
agents.
4. Soldering iron tip at 1/16” (1.6mm)
from housing
QEB373
SUBMINIATURE PLASTIC INFRARED
EMITTING DIODE
Parameter
Symbol
T
OPR
T
STG
T
SOL-I
T
SOL-F
I
F
V
R
P
D
Rating
-40 to +100
-40 to +100
240 for 5 sec
260 for 10 sec
50
5
100
Units
°C
°C
°C
°C
Operating Temperature
Storage Temperature
Soldering Temperature (Iron)
(2,3,4)
Soldering Temperature (Flow)
(2,3)
Continuous Forward Current
Reverse Voltage
Power Dissipation
(1)
mA
V
mW
ABSOLUTE MAXIMUM RATINGS
(T
A
= 25°C unless otherwise specified)
PARAMETER
Peak Emission Wavelength
Emission Angle
Forward Voltage
Reverse Current
Radiant Intensity
Rise Time
Fall Time
TEST CONDITIONS
I
F
= 100mA
I
F
= 100mA
I
F
= 100mA, t
P
= 20ms
V
R
= 5V
I
F
= 100mA, t
P
= 20ms
I
F
= 100mA,
t
P
= 20ms
SYMBOL
MIN.
—
—
—
—
16
—
—
TYP.
880
±12
—
—
—
800
800
MAX.
—
—
1.7
100
—
—
—
UNITS
nm
Deg.
l
P
U
V
F
I
R
I
e
t
r
t
f
V
μA
mW/sr
ns
ns
ELECTRICAL / OPTICAL CHARACTERISTICS
(T
A
=25°C)
PACKAGE DIMENSIONS
0.074 (1.9)
0.008 (0.21)
0.004 (0.11)
0.106 (2.7)
0.091 (2.3)
0.055 (1.4)
0.024 (0.6)
0.016 (0.4)
0.087 (2.2)
0.071 (1.8)
0.019 (0.5)
0.012 (0.3)
0.276 (7.0)
MIN
0.024 (0.6)
.059 (1.5)
.051 (1.3)
.118 (3.0)
.102 (2.6)
CATHODE
NOTES:
1. Dimensions are in inches (mm).
2. Tolerance of ± .010 (.25) on all non nominal dimensions
unless otherwise specified.
FEATURES
T-3/4 (2mm) Surface Mount Package
Tape & Reel Option (See Tape & Reel Specifications)
Lead Form Options: Gullwing, Yoke, Z-Bend
Narrow Emission Angle, 24°
Wavelength = 880nm, AlGaAs
Clear Lens
Matched Photosensor: QSB363
High Radiant Intensity
ANODE
CATHODE
SCHEMATIC
