3 of
4
100008A
SURFACE MOUNT OPTIONS
T-3/4 PACKAGES
NOTES: (Applies to all package drawings)
1. Dimensions are in inches (mm).
2. Tolerance of ± .010 (.25) on all non nominal dimensions
unless otherwise specified.
FEATURES
Three lead forming options: Gull Wing, Yoke and Z-Bend
Compatible with automatic placement equipment
Supplied on tape and reel or in bulk packaging
Compatible with vapor phase reflow solder processes
YOKE LEAD CONFIGURATION
0.074 (1.9)
0.055 (1.4)
0.087 (2.2)
0.071 (1.8)
0.118 (3.0)
0.102 (2.6)
0.020 (0.5)
0.016 (0.4)
0.043 (1.1)
0.098 (2.5)
0.051 (1.3)
0.141 (3.6)
0.031 (0.8)
ANODE
0.008 (0.2)
0.283 (7.2)
Z-BEND LEAD CONFIGURATION
0.074 (1.9)
0.106 (2.7)
0.091 (2.3)
0.055 (1.4)
0.087 (2.2)
0.071 (1.8)
0.024 (0.6)
.118 (3.0)
.102 (2.6)
0.020 (0.5)
0.016 (0.4)
0.080 (2.0)
0.043 (1.1)
0.236 (6.0)
0.220 (5.6)
0.177 (4.5)
0.161 (4.1)
0.031 (0.8)
ANODE
0.127 (3.25)
0.112 (2.85)
GULL WING LEAD CONFIGURATION
0.074 (1.9)
0.106 (2.7)
0.091 (2.3)
0.055 (1.4)
0.087 (2.2)
0.071 (1.8)
0.024 (0.6)
.118 (3.0)
.102 (2.6)
0.166 (4.2)
0.020 (0.51)
0.016 (0.4)
0.078 (2.0)
0.043 (1.1)
0.005 (0.13)
ANODE
