THS5661A
12-BIT, 125 MSPS, CommsDAC
DIGITAL-TO-ANALOG CONVERTER
SLAS247B – NOVEMBER 1999 REVISED SEPTEMBER 2002
23
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
APPLICATION INFORMATION
definitions of specifications and terminology (continued)
glitch energy
The time integral of the analog value of the glitch transient.
offset drift
The change in offset error versus temperature from the ambient temperature (TA = 25°C) in ppm of full-scale
range per
°C.
gain drift
The change in gain error versus temperature from the ambient temperature (TA = 25°C) in ppm of full-scale
range per
°C.
reference voltage drift
The change in reference voltage error versus temperature from the ambient temperature (TA = 25°C) in ppm
of full-scale range per
°C.
THS5661A evaluation board
An evaluation module (EVM) board for the THS5661A digital-to-analog converter is available for evaluation.
This board allows the user the flexibility to operate the THS5661A in various configurations. Possible output
configurations include transformer coupled, resistor terminated, and inverting/noninverting amplifier outputs.
The digital inputs are designed to interface with the TMS320 C5000 or C6000 family of DSPs or to be driven
directly from various pattern generators with the onboard option to add a resistor network for proper load
termination.
See the THS56x1 Evaluation Module User’s Guide for more details (SLAU032).
