TLE 6208-6 G
Data Sheet
3
2007-09-12
1.3
Pin Definitions and Functions
Pin No.
Symbol
Function
1OUTL5
Low-Side-Output 5; Power-MOS open drain with internal
reverse diode;
no internal clamp diode or active zenering;
short circuit protected and open load controlled.
2OUTH5
High-Side-Output 5; Power-MOS open source with internal
reverse diode;
no internal clamp diode or active zenering;
short circuit protected and open load controlled.
3OUTH4
High-Side-Output 4; see pin2.
4OUTL4
Low-Side-Output 4; see pin1.
5
V
S
Power supply; external connection to pin 10 necessary;
needs a blocking capacitor as close as possible to GND Value:
22
F electrolytic in parallel to 220 nF ceramic.
6, 7, 8, 9 GND
Ground; Reference potential; internal connection to pin 20, 21,
22 and 23;
cooling tab; to reduce thermal resistance; place cooling areas on
PCB close to this pins.
10
V
S
Power Supply; see pin 5.
11
OUTL3
Low-Side-Output 3; see pin1.
12
OUTH3
High-Side-Output 3; see pin2.
13
OUTH2
High-Side-Output 2; see pin2.
14
OUTL2
Low-Side-Output 2; see pin1.
15
OUTH1
High-Side-Output 1; see pin2.
16
OUTL1
Low-Side-Output 1; see pin1.
17
INH
Inhibit input; has an internal pull down;
device is switched in standby condition by pulling the INH
terminal low.
18
DO
Serial-Data-Output; this 3-state output transfers diagnosis data
to the control device; the output will remain 3-stated unless the
device is selected by a low on Chip-Select-Not (CSN); see
Table 2 for Diagnosis protocol.
19
V
CC
Logic supply voltage; needs a blocking capacitor as close as
possible to GND;
Value: 10
F electrolytic in parallel to 220 nF ceramic.
