TLE 6208-6 G
Data Sheet
9
2007-09-12
Table 3
Fault Result Table
Fault
Diag.-Bit
Result
Overcurrent (load)
13
Only the failed output is switched OFF.
Function and protection can be deactivated by
bit No. 13.
Short circuit to GND
(high-side-switch)
13
Only the failed output is switched OFF.
Function and protection can be deactivated by
bit No. 13.
Short circuit to
V
S
(low-side-switch)
13
Only the failed output is switched OFF.
Function and protection can be deactivated by
bit No. 13.
Temperature warning 0
Reaction of control device needed.
Temperature shut
down (SD)
–
All outputs OFF.
Openload
14
Only the failed output is switched OFF.
Function can be deactivated by bit No. 14.
Underload
14
Only the failed output is switched OFF.
Function can be deactivated by bit No. 14.
Undervoltage lockout
(UVLO)
15
All outputs OFF.
Overvoltage lockout
(OVLO)
15
All outputs OFF.
Function can be deactivated by bit No. 15.
H = failure;
L = no failure.
