TLE 6208-6 G
Data Sheet
4
2007-09-12
20, 21,
22, 23
GND
Ground
24
CSN
Chip-Select-Not input; CSN is an active low input; serial
communication is enabled by pulling the CSN terminal low; CSN
input should only be transitioned when CLK is low; CSN has an
internal active pull up and requires CMOS logic level inputs.
25
CLK
Serial clock input; clocks the shiftregister; CLK has an internal
active pull down and requires CMOS logic level inputs.
26
DI
Serial data input; receives serial data from the control device;
serial data transmitted to DI is an 16bit control word with the Least
Significant Bit (LSB) being transferred first: the input has an
active pull down and requires CMOS logic level inputs; DI will
accept data on the falling edge of CLK-signal; see Table 1 for
input data protocol.
27
OUTL6
Low-Side-Output 6; see pin1.
28
OUTH6
High-Side-Output 6; see pin2.
1.3
Pin Definitions and Functions (cont’d)
Pin No.
Symbol
Function
