TYPICAL CHARACTERISTICS
TABLE OF GRAPHS
TEST SET-UP FOR GRAPHS
IN+
IN-
OUT+
OUT-
VDD
GND
CI
RI
Measurement
Output
+
-
1 F
+
-
VDD
Load
30kHz
LowPass
Filter
Measurement
Input
+
-
Notes:
(1)CI wasShortedforanyCommon-Modeinputvoltagemeasurement
(2) A33- Hinductorwasplacedinserieswiththeloadresistortoemulateasmallspeakerforefficiencymeasurements.
.AnRClowpassfilter(100 ,47nF)is
usedoneachoutputforthedatasheetgraphs.
TPA2031D1
www.ti.com........................................................................................................................................................................................................ SLOS546 – MAY 2008
FIGURE
Efficiency
vs Output power
1, 2
PD
Power dissipation
vs Output power
3, 4
Supply current
vs Output power
5, 6
I(Q)
Quiescent current
vs Supply voltage
7
I(SD)
Shutdown current
vs Shutdown voltage
8
vs Supply voltage
9
PO
Output power
vs Load resistance
10, 11
vs Output power
12, 13
THD+N
Total harmonic distortion plus noise
vs Frequency
14, 15, 16, 17
vs Common-mode input voltage
18
KSVR
Supply voltage rejection ratio
vs Frequency
19, 20, 21
vs Time
22
GSM power supply rejection
vs Frequency
23
KSVR
Supply voltage rejection ratio
vs Common-mode input voltage
24
vs Frequency
25
CMRR
Common-mode rejection ratio
vs Common-mode input voltage
26
Voltage
vs Start-up time
27
Copyright 2008, Texas Instruments Incorporated
5
Product Folder Link(s): TPA2031D1
