參數資料
| 型號： | TPS40042DRCTG4 |
| 廠商： | TEXAS INSTRUMENTS INC |
| 元件分類： | 穩壓器 |
| 英文描述： | SWITCHING CONTROLLER, 700 kHz SWITCHING FREQ-MAX, PDSO10 |
| 封裝： | 3 X 3 MM, GREEN, PLASTIC, SON-10 |
| 文件頁數： | 1/35頁 |
| 文件大小： | 746K |
| 代理商： | TPS40042DRCTG4 |
當前第1頁第2頁第3頁第4頁第5頁第6頁第7頁第8頁第9頁第10頁第11頁第12頁第13頁第14頁第15頁第16頁第17頁第18頁第19頁第20頁第21頁第22頁第23頁第24頁第25頁第26頁第27頁第28頁第29頁第30頁第31頁第32頁第33頁第34頁第35頁
1
FEATURES
CONTENTS
DESCRIPTION
APPLICATIONS
1
2
3
4
10
9
8
7
HDRV
SW
BOOT
LDRV
EN
FB
COMP
VDD
TPS40042
6
GND
5
REFIN
UDG-07141
V
OUT
V
IN
Enable
Reference Input
SLUS777 – NOVEMBER 2007
www.ti.com
LOW PIN COUNT, LOW VIN (3.0 V TO 5.5 V) SYNCHRONOUS BUCK DC-TO-DC
CONTROLLER WITH EXTERNAL REFERENCE INPUT
2
3.0-V to 5.5-V Input
External Reference required: 0.5 V to 1.5 V
2
Output Voltage from REFIN to 90% of VIN
4
High-Side Drive for N-Channel FET
8
Supports Pre-Biased Outputs
10
Adaptive Anti-Cross Conduction Gate Drive
Fixed switching frequency (600 kHz) Voltage
18
Mode Control
28
Three Selectable Short Circuit Protection
Levels
Hiccup Restart from Faults
The TPS40042 DC/DC controller is designed to
Active Low Enable
operate with an input source between a 3.0 V and 5.5
Thermal Shutdown Protection at 145°C
V. To reduce the number of external components, a
number of operating parameters are fixed internally.
10-Pin, 3-mm x 3-mm SON (DRC)
The operating frequency for example, is internally set
at 600 kHz. (Continued)
DDR Memory
Point of Load
Telecommunications
DC to DC Modules
1
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
2
Predictive Gate Drive is a registered trademark of Texas Instruments.
PRODUCTION DATA information is current as of publication date.
Copyright 2007, Texas Instruments Incorporated
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
