TS2007
Absolute maximum ratings and operating conditions
3/29
1
Absolute maximum ratings and operating conditions
Table 1.
Absolute maximum ratings
Symbol
Parameter
Value
Unit
VCC
Supply voltage (1)
1.
All voltage values are measured with respect to the ground pin.
6V
Vi
Input voltage (2)
2.
The magnitude of the input signal must never exceed VCC + 0.3V / GND - 0.3V.
GND to VCC
V
Toper
Operating free air temperature range
-40 to + 85
°C
Tstg
Storage temperature
-65 to +150
°C
Tj
Maximum junction temperature
150
°C
Rthja
Thermal resistance junction to ambient (3)
3.
The device is protected in case of over temperature by a thermal shutdown active @ 150°C.
200
°C/W
Pd
Power dissipation
Internally limited(4)
4.
Exceeding the power derating curves during a long period will cause abnormal operation.
ESD
HBM: human body model
2
kV
ESD
MM: machine model
200
V
Latch-up
Latch-up immunity
Class A
Lead temperature (soldering, 10sec)
260
°C
Table 2.
Operating conditions
Symbol
Parameter
Value
Unit
VCC
Supply voltage
2.4 to 5.5
V
VI
Input voltage range
GND to VCC
V
Vic
Input common mode voltage(1)
1.
I Voo I ≤ 35mV max with both differential gains.
GND+0.15V to VCC-
0.7V
V
VSTBY
Standby voltage input (2)
Device ON
Device OFF
2.
Without any signal on VSTBY, the device is in standby (internal 300kΩ pull down resistor).
1.4
≤ VSTBY ≤ VCC
GND
≤ VSTBY ≤ 0.4 (3)
3.
Minimum current consumption is obtained when VSTBY = GND.
V
GS
Gain select input:
Gain =12dB
Gain = 6dB
GND
≤ VGS ≤ 0.4
1.4
≤ VGS ≤ VCC
V
RL
Load resistor
≥ 4
Ω
Rthja
Thermal resistance junction to ambient (4)
4.
When mounted on 4-layer PCB.
40
°C/W
