W9828BADA
128MB (16M x 64) PC100 SDRAM MODULE
Revision 0.9
1 OF 12
Publication Release Date:98/05/18
Features
Intel PC SDRAM compalint 168 pins, dual in-line memory module (DIMM)
Two memory rows on this module (Double Bank Module)
Unbuffered DIMM
Auto Refresh and Self Refresh
CAS latency: 2 and 3
Burst Length: 1, 2, 4, 8 and full page
4k refresh cycles/64ms
Interface: LVTTL
Serial Presence Detect with EEPROM
Single 3.3V
±
0.3V power supply
PCB: height (1,375 mil) single sided component
Part Number
Module Part Number
W9828BADA-8H
W9828BADA-8N
W9828BADA-10
Speed Grade
PC100 CL=2
PC100 CL=3
PC66
CL=2, 3
General Description
The Winbond W9828BADA is a 16M x 64 Synchronous Dynamic RAM memory module. This module consists of
sixteen pieces of W986408AH (8M x 8 bit) SDRAMs in 54-pin TSOP-II 400mil package and a 2K EEPROM in 8-pin SOP
package on a 168-pin 6-layer PCB. One 0.1 uF and one 0.33uF decoupling capacitor is used for each SDRAM.
The W9828BADA is a Dual In-line Memory Module for mounitng into 84-pin dual readout zigzag edge connector
sockets. It is designed to operate in 3.3V memory systems.
