| 型號： | 203181 |
| 廠商： | ERNI ELECTRONICS INC |
| 元件分類： | 電信和以太網連接器 |
| 英文描述： | 32 CONTACT(S), FEMALE, TELECOM AND DATACOM CONNECTOR, SOLDER, JACK |
| 文件頁數： | 1/2頁 |
| 文件大小： | 42K |
| 代理商： | 203181 |
29APR03
d
8C10T, 1X4, INTEGRATED MAGNETICS
MJIM
MOD JACK - MJIM
2:1
-
203181
EMPFOHLENER FUER LEITERPLATTE - BESTUCKUNGSSEITE
ALL TOLERANCES
±0.05 [.002] UNLESS NOTED
RECOMMENDED PCB LAYOUT - COMPONENT SIDE VIEW
1
10
1
10
1
8
1
8
1
8
1
8
10
40.64 [1.600]
12.70 [.500]
8.89
[.350]
2.54
[.100]
1.27 [.050]
26.67 [1.050]
10.16
[.400]
3.68
[.145]
2.54 [.100]
3.25
±0.08 [
.128
±.003] X2
1.60
±0.08 [
.063
±.003] X5
53.34 [2.100]
10.89 [.429]
3.20
±0.20
[.126
±.008]
13.80
[.543]
21.59
[.850]
MAX
59.09 [2.326]
53.34
±0.13 [2.100±.005]
0.89
±0.07 [
.035
±0.003] X40
3 x 13.97[.550] = (41.91 [1.650])
11.43 [.450]
25.40 [1.000]
39.37 [1.550]
53.34 [2.100]
2.73 [.107]
HOUSING: GLASS FILLED POLYESTER UL 94 V-0 BLACK
CONTACT RESISTANCE: 30 MILLIOHMS MAX
ELECTRICAL CHARACTERISTICS
OPERATING TEMPERATURE: 0C TO 70C
TERMINAL FINISH: SnPb
MECHANICAL CHARACTERISTICS
DURABILITY: 1000 MATING CYCLES
CONTACT FINISH: Au, 0.8
m [30 in], OVER Ni
MATERIALS AND FINISH
CONTACTS: PHOSPHOR BRONZE
SHIELDING: Cu ALLOY, PLATED WITH Ni
NOTE 1: REAR SHIELD TABS BETWEEN EACH PORT (T)
NOTE 2: PANEL GROUND FLANGES BOTH SIDES AND TOP (GF5)
NOTE 3. SIDE GROUND TABS IN FRONT OF PEG 3.68mm (F2)
Date
Rev.
in mm
ERNI Components
CHESTER, VA U.S.A.
Group/Type
[in]
I
Scale
Designation
Tolerances
Consider
pr
otection
memo
fr
om
DIN
34
All rights reserved.
Only for information.
To insure that this is the latest
version of this drawing, please
contact one of the ERNI companies
before using.
Subject to modification without
prior notice.
Drawing will not be updated.
Information:
All Dimensions
SCHMATIC NO.: M5A01
