| 型號： | 203181 |
| 廠商： | ERNI ELECTRONICS INC |
| 元件分類： | 電信和以太網連接器 |
| 英文描述： | 32 CONTACT(S), FEMALE, TELECOM AND DATACOM CONNECTOR, SOLDER, JACK |
| 文件頁數： | 2/2頁 |
| 文件大小： | 42K |
| 代理商： | 203181 |
29APR03
d
8C10T, 1X4, INTEGRATED MAGNETICS
MJIM
MOD JACK - MJIM
2:1
-
203181
-10dB MIN
-14.5dB MIN
-12dB MIN
350
H MIN
MAGNETIC SPECIFICATIONS @ 25C
INSERTION LOSS (0.1-100MHz): -1.1dB MAX
1,500 Vrms
CROSSTALK (0.1-100MHz): -[33-20log(F/100MHz)]dB TYP
CMR (0.1-100MHz)
-40dB TYP.
60MHz
100MHz
80MHz
RETURN LOSS:
1-40MHz
-18dB MIN
OCL (100KHz, 0.1V, 8mA):
ISOLATION
LP
EMPFOHLENER FRONTPLATTEN AUSSCHNITT
RECOMMENDED PANEL
CUTOUT
TOP OF PCB
ELECTRICAL SCHEMATICS 1000 BASE T - M5A01
1000 pf/2KV
0.01
f X4
GND P10
VCC
P9
TD3+ P7
TD3- P8
4X 75W
ELEKTRISCHES DIAGRAMM
TD1+ P3
TD1- P6
TD2- P5
TD2+ P4
TD0- P2
TD0+ P1
PC
B
CMR
CHOKES
J7 MX3+
J8 MX3-
J3 MX1+
J6 MX1-
J5 MX2-
J4 MX2+
J1 MX0+
J2 MX0-
CABL
E
0.38
±0.10
[.015
±.004]
60.19
±0.20 [2.370±.008]
14.89
[.586]
Date
Rev.
in mm
ERNI Components
CHESTER, VA U.S.A.
Group/Type
[in]
I
Scale
Designation
Tolerances
Consider
pr
otection
memo
fr
om
DIN
34
All rights reserved.
Only for information.
To insure that this is the latest
version of this drawing, please
contact one of the ERNI companies
before using.
Subject to modification without
prior notice.
Drawing will not be updated.
Information:
SCHMATIC NO.: M5A01
All Dimensions
