AD9858
ABSOLUTE MAXIMUM RATINGS
Table 2.
Parameter
AV
DD
DV
DD
CPV
DD
Digital Input Voltage
Digital Output Current
Storage Temperature
Operating Temperature
θ
JA
EPAD Soldered
Rev. A | Page 6 of 32
Rating
4 V
4 V
6 V
–0.7 V to +V
DD
5 mA
–65°C to +150°C
–40°C to +85°C
25°C/W
Absolute Maximum Ratings are limiting values, to be applied
individually, and beyond which the serviceability of the circuit
may be impaired. Functional operability under any of these
conditions is not necessarily implied. Exposure of absolute
maximum rating conditions for extended periods of time may
affect device reliability.
Table 3. Explanation of Test Levels
I
100% Production Tested.
III
Sample Tested Only.
IV
Parameter is guaranteed by design and characterization
testing.
V
Parameter is a typical value only.
VI
Devices are 100% production tested at 25°C and
guaranteed by design and characterization testing for
industrial operating temperature range.
ESD CAUTION
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily accumulate on the
human body and test equipment and can discharge without detection. Although this product features
proprietary ESD protection circuitry, permanent damage may occur on devices subjected to high energy
electrostatic discharges. Therefore, proper ESD precautions are recommended to avoid performance
degradation or loss of functionality.
