Preliminary Technical Data
ADCMP580/ADCMP581/ADCMP582
ABSOLUTE MAXIMUM RATINGS
Table 2.
Parameter
SUPPLY VOLTAGES
Positive Supply Voltage
(V
CCI
to GND)
Negative Supply Voltage
(V
EE
to GND)
Logic Supply Voltage
(V
CCO
to GND)
INPUT VOLTAGES
Input Voltage
Differential Input Voltage
Input Voltage, Latch Enable
HYSTERESIS CONTROL PIN
Applied Voltage (HYS to V
EE
)
Maximum Input/Output Current
OUTPUT CURRENT
ADCMP580 (CML)
ADCMP581 (NECL)
ADCMP582 (PECL)
TEMPERATURE
Operating Temperature, Ambient
Operating Temperature, Junction
Storage Temperature Range
Rev. PrA | Page 5 of 16
Rating
0.5 V to +6.0 V
–6.0 V to +0.5 V
0.5 V to +6.0 V
3.0 V to +4.0 V
2.5 V to +2.5 V
2.5 V to +5.5 V
5.5 V to +0.5 V
1 mA
25 mA
40 mA
40 mA
40°C to +85°C
125°C
65°C to +150°C
ESD CAUTION
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily accumulate on
the human body and test equipment and can discharge without detection. Although this product features
proprietary ESD protection circuitry, permanent damage may occur on devices subjected to high energy
electrostatic discharges. Therefore, proper ESD precautions are recommended to avoid performance
degradation or loss of functionality.
THERMAL CONSIDERATIONS
The ADCMP580/ADCMP581/ADCMP582 LFCSP 16-lead
package option has a θ
JA
(junction to ambient thermal
resistance) of 70°C/W in still air.
Stress above those listed under Absolute Maximum Ratings may
cause permanent damage to the device. This is a stress rating
only and functional operation of the device at these or any other
conditions above those indicated in the operational sections of
this specification is not implied. Exposure to absolute maximum
rating conditions for extended periods may affect device
reliability.
