ADF7020
Preliminary Technical Data
ABSOLUTE MAXIMUM RATINGS
T
A
= 25°C, unless otherwise noted.
Table 3.
Parameter
V
DD
to GND
1
Analog I/O Voltage to GND
Digital I/O Voltage to GND
Operating Temperature Range
Industrial (B Version)
Storage Temperature Range
Maximum Junction Temperature
MLF
θ
JA
Thermal Impedance
Lead Temperature Soldering
Vapor Phase (60 s)
Infrared (15 s)
Rev. PrH | Page 8 of 40
Rating
0.3 V to +5 V
0.3 V to AV
DD
+ 0.3 V
0.3 V to DV
DD
+ 0.3 V
40°C to +85°C
65°C to +125°C
125°C
TBD°C/W
235°C
240°C
1
GND = CPGND = RFGND = DGND = AGND = 0 V.
Stresses above those listed under Absolute Maximum Ratings
may cause permanent damage to the device. This is a stress
rating only and functional operation of the device at these or
any other conditions above those indicated in the operational
section of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect
device reliability.
This device is a high-performance RF integrated circuit with an
ESD rating of <2 kV and it is ESD sensitive. Proper precautions
should be taken for handling and assembly.
ESD CAUTION
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily accumulate on
the human body and test equipment and can discharge without detection. Although this product features
proprietary ESD protection circuitry, permanent damage may occur on devices subjected to high energy
electrostatic discharges. Therefore, proper ESD precautions are recommended to avoid performance
degradation or loss of functionality.
