5 Channel Data Format
The channel interface is responsible for outputting the compressed data from the encoder and inputting compressed data to the
decoder. In addition to these most basic functions the channel interface is also capable of reporting certain events, such as the
detection of a DTMF tone. The channel interface can also control certain selectable functions of the AMBE-2000, such as
the voice coding rate. This chapter will describe how the AMBE-2000 uses the channel interface to multiplex these
capabilities.
There are two formats to the data,
Formatted
and
Unformatted
, both of which operate in serial mode. Generally speaking the
Unformatted
mode is used only when the connection between the AMBE-2000 and the channel under design is relatively
direct, and the designer wants to simplify the extraction of the relevant voice data. In this mode configuration is accomplished
using hardwired pins. In most cases, when a controller is present between the AMBE-2000 and the channel, the system
designer will find that using the
Formatted
format is more flexible.
5.1
Formatted Format
The
Formatted
format is a 24 by sixteen-bit word format for a total of 48 bytes or 384 bits. Every 20 milliseconds the encoder
outputs 24 sixteen-bit words, and likewise the decoder expects to receive 24 words. The format of the input and output frames
are detailed below. The first 12 sixteen bit words are made up of header, ID and status or control information. The remaining
12 sixteen bit words make up the encoded data bit field. These 12 words, or 192 bits, will be fully populated with relevant
voice data only when the AMBE-2000 is operating in a 9600bps mode (9600 bits/sec
÷
50 frames/sec = 192 bits/frame).
Otherwise, when the data rate is less than 9600bps, the coded voice bits are filled starting from the MSB of the first word in the
field, leaving any unused bits as zeros. It is important to note here that even when the AMBE-2000 is operating at less than
9600bps,
all
384 bits of the
Formatted
format (including any unused trailing zeros) must be transferred out of the encoder and
into the decoder.
5.2
Formatted Input Format
The format of the
Formatted
input is shown in Figure 5-A. Keep in mind that even though the channel data in this
Formatted
input format is closely associated with the decoder, the control information will apply to both encoder
and
decoder functions.
