FAN8402D (KA3081D)
10
3. PRINCIPLE OF OPERATION
Input circuit of 3-phase motor drive with soft-switching function is shown as the figure 3.
Figure 3.
Next the figure 4 shows common signal (Hall signal) and each individual stairwave at its own position.
Figure 4.
Figure 5 shows hall signal and stairwave signal position.
The section where the difference between hall signal and stairwave is within 100mV.
Hall
: Hall common signal taken from sub-magnet.
Hall+: Stairwave signal with 120 degree wave angle difference from one signal.
I
C1
I
C2
I
C3
I
C4
I
C5
I
C6
Q1
Q2
Q3
Q4
Q5
Q6
Hall+
Hall
V-stair wave
W-stair wave
I
EE
I
EE
I
EE
U-stair wave
Common signal
1 Hall Signal
U-Stair Wave
W-Stair Wave
V-Stair Wave
