FAN8402D (KA3081D)
11
Figure 5.
4. PEAK DETECTOR
Hall signals and stairwave signals made from peak detectors’s output rotate the motor.
The peak detector circuit is shown in Fig 6.
Figure 6.
V
ABS
in the figure 6 is a signal from twice amplified hall signal and hall bias at 2.5 volt as standard voltage as you see in the
figure 7.
Region
A
Rigion
B
100mV
(a) The difference between 1 hall signal and U-stair wave
(b) The difference between 1 hall signal and V-stair wave
(c) The difference between 1 hall signal and W-stair wave
+
AMP
+
+
V
ABS
V’
REF
ck_zero
V
A
COMP2
V
Y
V
REF
D1
D2
ck_peak
C_PK
R
L
C
COMP1
