F
FDR8521L Rev. C
FDR8521L
P-Channel MOSFET With Gate Driver For Load Switch Application
General Description
This device is designed for configuration as a load switch
and is particularly suited for power management in por-
table battery powered electronic equipment. Designed to
operate from 3V to 20V input and supply up to 2.9A, the
device features a small N-Channel MOSFET (Q1) together
with a large P-Channel Power MOSFET (Q2) in a single
SO-8 package.
August 2000
Features
V
V
DROP
= 0.07 V @ V
DROP
= 0.115 V @ V
IN
= 12 V, I
IN
= 5 V, I
L
= 1 A.R
(ON)
= 0.07
L
= 1 A.R
(ON)
= 0.115
.
V
V
DROP
= 0.2 V @ V
DROP
= 0.2 V @ V
IN
= 12 V, I
IN
= 5 V,I
=2.9 A.R
(ON)
= 0.07
L
= 1.8 A.R
(ON)
= 0.115
.
Control MOSFET (Q1) includes Zener protection for
ESD ruggedness (>6kV Human Body Model).
High density cell design for extremely low on-resistance.
2000 Fairchild Semiconductor International
Absolute Maximum Ratings
T
A
=25
o
C unless otherwise noted
Symbol
V
IN
V
ON/OFF
I
D
Parameter
Ratings
3 - 20
2.5 - 8
2.9
8
0.8
-55 to +150
6
Units
V
V
A
Input Voltage Range
(Note 1)
On/Off Voltage Range
Load Current
- Continuous
- Pulsed
Maximum Power Dissipation
(Note 2)
Operating and Storage Temperature Range
Electrostatic Discharge Rating MIL-STD-883D
Human-Body-Model (100pf/1500 Ohm)
(Note 2)
P
D
T
J
, T
stg
ESD
W
°
C
kV
Thermal Characteristics
R
θ
JA
R
θ
JC
Thermal Resistance, Junction-to-Ambient
(Note 2)
Thermal Resistance, Junction-to-Case
(Note 2)
156
40
°
C/W
°
C/W
Package Marking and Ordering Information
Device Marking
Device
Reel Size
Tape width
Quantity
8521L
FDR8521L
13’’
12mm
3000 units
Applications
Power management
Load switch
IN
OUT
ON/OFF
EQUIVALENT CIRCUIT
V
DROP
+
-
SuperSOT -8
TM
pin
1
1
5
7
8
6
4
3
2
Q2
Q1
See Application Circuit
R
2
V
ON/OFF
R
1
,R
2
,C
1
V
OUT,
C
1,
C
O
C
1
,C
O
R
2
V
IN
,R
1
,C
i
V
OUT,
C
1,
C
O
