2002 Fairchild Semiconductor Corporation
F
Rev. A, September 2002
Mechanical Characteristics and Ratings
Fig. 8. Flatness Measurement Position of The Ceramic Substrate
Note:
7. Do not make over torque or mounting screws. Much mounting torque may cause ceramic cracks and bolts and Al heat-fin destruction.
8. Avoid one side tightening stress. Fig.9 shows the recommended torque order for mounting screws. Uneven mounting can cause the SPM ceramic substrate to
be damaged.
Fig. 9. Mounting Screws Torque Order
Item
Condition
Limits
Typ.
10
0.98
-
35
Unit
Min.
8
0.78
0
-
Max.
12
1.17
+120
-
Mounting Torque
Mounting Screw: M4
(Note 7 and 8)
Recommended 10Kgcm
Recommended 0.98Nm
Note Fig.8
Kgcm
Nm
um
g
Ceramic Flatness
Weight
(+)
(+)
(+)
Datum Line
1
2
