LC72715PW
No.A1650-14/26
CPU Registers
This LSI has both write registers and read registers. Access to the registers is made via CCB IF or parallel IF. Switching
of access mode is made with the SP pin. (CCB IF: SP=H, Parallel IF: SP=L)
(1) Write registers
Setting any data to ‘0h’ or ‘7h’ or larger address of Write-registers is prohibited. Do not set any data to these addresses.
List of write registers
ADR
R/W
Register Name
Description
0h
-
Reserved (setting prohibited)
1h
W
BIC
Allowable number of BIC errors
2h
W
SYNCB
Block synchronization: error protection count
3h
W
SYNCF
Frame synchronization: error protection count
4h
W
CTL1
Control register 1
5h
W
CTL2
Control register 2
6h
W
CRC4
Layer 4 CRC register (for the parallel IF only. CCB to use the dedicated address)
7h and beyond
-
Reserved (setting prohibited)
1h <BIC>: Number of allowable BIC errors <Write Only>
Register to set the allowable number of BIC error bits for determination of synchronization
ADR
Register Name
Bit
Name
Description
Reset
7-4
BIC_B
Backward protection value (initial value 2)
Sets the number of allowable BIC error bits (when not synchronized).
0010b
1h
BIC
3-0
BIC_F
Forward protection value (initial value 2)
Sets the allowable number of BIC error bits (when synchronized).
0010b
When the block synchronization determination output (BLOCK) is to be used determination of whether or not there is
any FM multiplex data, it is recommended to set the allowable number of BIC errors during backward protection to
‘0001b’ or ‘0000b’.
