參數資料
| 型號： | MAX6581TG9A+ |
| 廠商： | Maxim Integrated |
| 文件頁數： | 21/27頁 |
| 文件大小： | 1212K |
| 描述： | IC TEMP SENSOR 8-CH PREC 24-TQFN |
| 產品培訓模塊： | Lead (SnPb) Finish for COTS Obsolescence Mitigation Program |
| 標準包裝： | 75 |
| 功能： | 溫度監控器 |
| 傳感器類型： | 內部和外部 |
| 感應溫度： | -64°C ~ 150°C |
| 精確度： | ±3°C 本地（最大），±2.5°C 遠程（最大） |
| 輸出類型： | I²C?/SMBus? |
| 輸出警報： | 是 |
| 輸出風扇： | 是 |
| 電源電壓： | 3 V ~ 3.6 V |
| 工作溫度： | -40°C ~ 125°C |
| 安裝類型： | 表面貼裝 |
| 封裝/外殼： | 24-WFQFN 裸露焊盤 |
| 供應商設備封裝： | 24-TQFN-EP（4x4） |
| 包裝： | 管件 |
第1頁第2頁第3頁第4頁第5頁第6頁第7頁第8頁第9頁第10頁第11頁第12頁第13頁第14頁第15頁第16頁第17頁第18頁第19頁第20頁當前第21頁第22頁第23頁第24頁第25頁第26頁第27頁
21
Maxim Integrated
?癈 Accurate 8-Channel Temperature Sensor
MAX6581
Series-Resistance Cancellation
Some thermal diodes on high-power ICs have exces-
sive series resistance that can cause temperature-mea-
surement errors when used with conventional remote-
temperature sensors. Channels 17 of the MAX6581
have a series-resistance cancellation feature (enabled
by bits [7:0] of the Resistance Cancellation register)
that eliminates the effect of diode series resistance and
interconnection resistance. Set these bits to 1 if the series
resistance is large enough to affect the accuracy of the
channels. The series-resistance cancellation function
increases the conversion time for the remote channels by
125ms (typ). This feature cancels the bulk resistance of
the sensor and any other resistance in series (e.g., wire,
contact resistance, etc.). The cancellation range is from
0I to 100I.
Table 12. Resistance Cancellation Register (4Ah)
X = Dont care.
BIT
NAME
POR
STATE
FUNCTION
7 (MSB)
X
0
6
Resistance
Cancellation 7
0
Channel 7 Resistance Cancellation Enable Bit. Set this bit to logic 1 to enable
resistance cancellation. Set this bit to logic 0 to disable resistance cancellation.
5
Resistance
Cancellation 6
0
Channel 6 Resistance Cancellation Enable Bit. Set this bit to logic 1 to enable
resistance cancellation. Set this bit to logic 0 to disable resistance cancellation.
4
Resistance
Cancellation 5
0
Channel 5 Resistance Cancellation Enable Bit. Set this bit to logic 1 to enable
resistance cancellation. Set this bit to logic 0 to disable resistance cancellation.
3
Resistance
Cancellation 4
0
Channel 4 Resistance Cancellation Enable Bit. Set this bit to logic 1 to enable
resistance cancellation. Set this bit to logic 0 to disable resistance cancellation.
2
Resistance
Cancellation 3
0
Channel 3 Resistance Cancellation Enable Bit. Set this bit to logic 1 to enable
resistance cancellation. Set this bit to logic 0 to disable resistance cancellation.
1
Resistance
Cancellation 2
0
Channel 2 Resistance Cancellation Enable Bit. Set this bit to logic 1 to enable
resistance cancellation. Set this bit to logic 0 to disable resistance cancellation.
0
Resistance
Cancellation 1
0
Channel 1 Resistance Cancellation Enable Bit. Set this bit to logic 1 to enable
resistance cancellation. Set this bit to logic 0 to disable resistance cancellation.
