MPC9230
MOTOROLA
TIMING SOLUTIONS
Table 1. Pin Configurations
Pin
I/O
Default
Type
Function
XTAL_IN, XTAL_OUT
Analog
Crystal oscillator interface
FREF_EXT
Input
0
LVCMOS
Alternative PLL reference input
F
OUT
, F
OUT
Output
LVPECL
Differential clock output
TEST
Output
LVCMOS
Test and device diagnosis output
XTAL_SEL
Input
1
LVCMOS
PLL reference select input
S_LOAD
Input
0
LVCMOS
Serial configuration control input.
This input controls the loading of the configuration latches with the contents of the shift
register. The latches will be transparent when this signal is high, thus the data must
be stable on the high-to-low transition.
P_LOAD
Input
1
LVCMOS
Parallel configuration control input.
This input controls the loading of the configuration latches with the content of the
parallel inputs (M and N). The latches will be transparent when this signal is low, thus
the parallel data must be stable on the low-to-high transition of P_LOAD. P_LOAD is
state sensitive.
S_DATA
Input
0
LVCMOS
Serial configuration data input.
S_CLOCK
Input
0
LVCMOS
Serial configuration clock input.
M[0:8]
Input
1
LVCMOS
Parallel configuration for PLL feedback divider (M).
M is sampled on the low-to-high transition of P_LOAD.
N[1:0]
Input
1
LVCMOS
Parallel configuration for Post-PLL divider (N).
N is sampled on the low-to-high transition of P_LOAD.
OE
Input
1
LVCMOS
Output enable (active high)
The output enable is synchronous to the output clock to eliminate the possibility of runt
pulses on the F
OUT
output.
GND
Supply
Ground
Negative power supply (GND).
V
CC
Supply
V
CC
Positive power supply for I/O and core. All V
CC
pins must be connected to the positive
power supply for correct operation.
V
CC_PLL
Supply
V
CC
PLL positive power supply (analog power supply).
Table 2. Output Frequency Range and PLL Post-Divider N
N
Output Division
Output Frequency Range
for T
A
= 0°C to +70°C
Output Frequency Range
for T
A
= –40°C to +85°C
1
0
0
0
2
200 – 400 MHz
200 – 375 MHz
0
1
4
100 – 200 MHz
100 – 187.5 MHz
1
0
8
50 – 100 MHz
50 – 93.75 MHz
1
1
1
400 – 800 MHz
400 – 750 MHz
Table 3. Function Table
Input
0
1
XTAL_SEL
FREF_EXT
XTAL interface
OE
Outputs disabled. F
OUT
is stopped
in the logic low state
(F
OUT
= L, F
OUT
= H)
Outputs enabled
F
