MOTOROLA
SEMICONDUCTOR TECHNICAL DATA
Order Number: MPC9448/D
Rev 3, 04/2003
Motorola, Inc. 2003
3.3V/2.5V LVCMOS 1:12 Clock
Fanout Buffer
The MPC9448 is a 3.3V or 2.5V compatible, 1:12 clock fanout buffer
targeted for high performance clock tree applications. With output
frequencies up to 350 MHz and output skews less than 150 ps, the device
meets the needs of most demanding clock applications.
12 LVCMOS compatible clock outputs
Selectable LVCMOS and differential LVPECL compatible clock inputs
Maximum clock frequency of 350 MHz
Maximum clock skew of 150 ps
Synchronousoutput stopinlogiclowstateeliminatesoutput runtpulses
High--impedance output control
3.3V or 2.5V power supply
Drives up to 24 series terminated clock lines
Ambient temperature range --40
°
C to +85
°
C
32--Lead LQFP packaging
Supports clock distribution in networking, telecommunication and
computing applications
Pin and function compatible to MPC948
Functional Description
The MPC9448 is specifically designed to distribute LVCMOS
compatible clock signals up to a frequency of 350 MHz. Each output
provides a precise copy of the input signal with a near zero skew. The
outputs buffers support driving of 50
terminated transmission lines on
the incident edge: each output is capable of driving either one parallel
terminated or two series terminated transmission lines.
Two selectable, independent clock inputs are available, providing support of LVCMOS and differential LVPECL clock
distribution systems. The MPC9448 CLK_STOP control is synchronous to the falling edge of the input clock. It allows the start
and stop of the output clock signal only in a logic low state, thus eliminating potential output runt pulses. Applying the OE control
will force the outputs into high--impedance mode.
All inputs have an internal pull--up or pull--down resistor preventing unused and open inputs from floating. The device supports
a 2.5V or 3.3V power supply and an ambient temperature range of --40
°
C to +85
°
C. The MPC9448 is pin and function compatible
but performance--enhanced to the MPC948.
LOW VOLTAGE
3.3V/2.5V LVCMOS 1:12
CLOCK FANOUT BUFFER
MPC9448
FA SUFFIX
32--LEAD LQFP PACKAGE
CASE 873A
F
For More Information On This Product,
Go to: www.freescale.com
n
.
