MRFG35002N6T1 replaced by MRFG35002N6AT1.
MRFG35002N6T1
1
RF Device Data
Freescale Semiconductor
Gallium Arsenide PHEMT
RF Power Field Effect Transistor
Designed for WLL/MMDS/BWA or UMTS driver applications. Characterized
from 500 to 5000 MHz. Device is unmatched and is suitable for use in Class AB
Customer Premise Equipment (CPE) applications.
Typical Single-Carrier W-CDMA Performance: VDD = 6 Volts, IDQ =
65 mA, Pout = 158.5 mWatts Avg., 3550 MHz, Channel Bandwidth =
3.84 MHz, PAR = 8.5 dB @ 0.01% Probability on CCDF.
Power Gain — 10 dB
Drain Efficiency — 27%
ACPR @ 5 MHz Offset — -41 dBc in 3.84 MHz Channel Bandwidth
1.5 Watts P1dB @ 3550 MHz, CW
Excellent Phase Linearity and Group Delay Characteristics
High Gain, High Efficiency and High Linearity
RoHS Compliant.
In Tape and Reel. T1 Suffix = 1000 Units per 12 mm, 7 inch Reel.
Table 1. Maximum Ratings
Rating
Symbol
Value
Unit
Drain-Source Voltage
VDSS
8
Vdc
Gate-Source Voltage
VGS
-5
Vdc
RF Input Power
Pin
22
dBm
Storage Temperature Range
Tstg
-65 to +150
°C
Channel Temperature (1)
Tch
175
°C
Operating Case Temperature Range
TC
-20 to +85
°C
Table 2. Thermal Characteristics
Characteristic
Symbol
Value (2)
Unit
Thermal Resistance, Junction to Case
RθJC
15.2
°C/W
Table 3. Moisture Sensitivity Level
Test Methodology
Rating
Package Peak Temperature
Unit
Per JESD 22-A113, IPC/JEDEC J-STD-020
1
260
°C
1. For reliable operation, the operating channel temperature should not exceed 150°C.
2. Refer to AN1955, Thermal Measurement Methodology of RF Power Amplifiers. Go to http://www.freescale.com/rf.
Select Documentation/Application Notes - AN1955.
LIFETIME
BUY
LAST
ORDER
8
DEC
07
LAST
SHIP
8
JUN
08
Document Number: MRFG35002N6
Rev. 2, 1/2008
Freescale Semiconductor
Technical Data
3.5 GHz, 1.5 W, 6 V
POWER FET
GaAs PHEMT
MRFG35002N6T1
CASE 466-03, STYLE 1
PLD-1.5
PLASTIC
Freescale Semiconductor, Inc., 2006, 2008. All rights reserved.
