DATA SHEET
HJ-FET
NE34018
L to S BAND LOW NOISE AMPLIFIER
N-CHANNEL HJ-FET
1996
Document No. P11618EJ3V0DS00 (3rd edition)
Date Published September 1997 N
Printed in Japan
DESCRIPTION
NE34018 is a n-channel HJ-FET housed in MOLD package.
FEATURES
Low noise figure
NF = 0.6 dB TYP. at f = 2 GHz
High associated gain
Ga = 16 dB TYP. at f = 2 GHz
Gate width: Wg = 400
P
m
4 pins super mini mold
Tape & reel packaging only available
x
x
x
x
x
ORDERING INFORMATION
PART NUMBER
QUANTITY
PACKING STYLE
NE34018-T1
3 Kpcs/Reel.
Embossed tape 8 mm wide. Pin 3
(Source), Pin 4 (Drain) face to
perforation side of the tape.
NE34018-T2
3 Kpcs/Reel.
Embossed tape 8 mm wide. Pin 1
(Source), Pin 2 (Gate) face to
perforation side of the tape.
*
Please contact with responsible NEC person, if you require evaluation
sample. Unit sample quantity shall be 50 pcs. (Part number for sample
order: NE34018)
ABSOLUTE MAXIMUM RATINGS (T
A
= 25
q
C)
Drain to Source Voltage
Gate to Source Voltage
Gate Current
Total Power Dissipation
Channel Temperature
Storage Temperature
V
DS
V
GS
I
D
P
tot
T
ch
T
stg
4.0
e
3.0
I
DSS
150
125
V
V
mA
mW
q
C
q
C
e
65 to +125
PACKAGE DIMENSIONS
in millimeters
V
2.1 ±0.2
1.25 ±0.1
(
(
2
0
0
0
0
0
1
2
4
3
0
+
–
0
+
–
0
+
–
0
+
–
0
+
–
PIN CONNECTIONS
1. Source
2. Gate
3. Source
4. Drain
