120
S29GLxxxM MirrorBitTM Flash Family
S29GLxxxM_00_B1_E August 4, 2004
Data she e t
After the sector erase command is written, the system should read the status of DQ7 (Data# Polling) or DQ6 (Tog-
gle Bit I) to ensure that the device has accepted the command sequence, and then read DQ3. If DQ3 is “1,” the
Embedded Erase algorithm has begun; all further commands (except Erase Suspend) are ignored until the erase
operation is complete. If DQ3 is “0,” the device will accept additional sector erase commands. To ensure the com-
mand has been accepted, the system software should check the status of DQ3 prior to and following each
subsequent sector erase command. If DQ3 is high on the second status check, the last command might not have
been accepted.
Table 37 shows the status of DQ3 relative to the other status bits.
DQ1: Write-to-Buffer Abort
DQ1 indicates whether a Write-to-Buffer operation was aborted. Under these conditions DQ1 produces a “1”. The
system must issue the Write-to-Buffer-Abort-Reset command sequence to return the device to reading array data.
See Write Buffer section for more details.
Table 37. Write Operation Status
Notes:
1. DQ5 switches to ‘1’ when an Embedded Program, Embedded Erase, or Write-to-Buffer operation has exceeded the
maximum timing limits. Refer to the section on DQ5 for more information.
2. DQ7 and DQ2 require a valid address when reading status information. Refer to the appropriate subsection for
further details.
3. The Data# Polling algorithm should be used to monitor the last loaded write-buffer address location.
4. DQ1 switches to ‘1’ when the device has aborted the write-to-buffer operation
Status
DQ7
(Note 2)
DQ6
DQ5
(Note 1)
DQ3
DQ2
(Note 2)
DQ1
RY/
BY#
Standard
Mode
Embedded Program Algorithm
DQ7#
Toggle
0
N/A
No toggle
0
Embedded Erase Algorithm
0
Toggle
0
1
Toggle
N/A
0
Program
Suspend
Mode
Program-
Suspend
Read
Program-Suspended
Sector
Invalid (not allowed)
1
Non-Program
Suspended Sector
Data
1
Erase
Suspend
Mode
Erase-
Suspend
Read
Erase-Suspended
Sector
1
No toggle
0
N/A
Toggle
N/A
1
Non-Erase
Suspended Sector
Data
1
Erase-Suspend-Program
(Embedded Program)
DQ7#
Toggle
0
N/A
0
Write-to-
Buffer
Busy (Note 3)
DQ7#
Toggle
0
N/A
0
Abort (Note 4)
DQ7#
Toggle
0
N/A
1
0
