參數資料
型號： S29GL032M10BFIR22
廠商： SPANSION LLC
元件分類： PROM
英文描述： T528 Series - I, M, Z Case Sizes - Face Down Termination Tantalum Surface Mount Capacitor; Capacitance [nom]: 220uF; Working Voltage (Vdc)[max]: 4V; Capacitance Tolerance: +/-20%; Dielectric: Tantalum, Solid; ESR: 12mΩ; Lead Style: Surface-Mount Chip; Lead Dimensions: 7343-17; Termination: 100% Tin (Sn); Body Dimensions: 7.3mm x 4.3mm x 1.7mm; Temperature Range: -55C to +105C; Container: Tape & Reel; Qty per Container: 1,000; Features: Face Down Termination
中文描述： 2M X 16 FLASH 3V PROM, 100 ns, PBGA64
封裝： 13 X 11 MM, LEAD FREE, FORTIFIED BGA-64
文件頁數： 42/158頁
文件大小： 4695K
代理商： S29GL032M10BFIR22
136
S29GLxxxM MirrorBitTM Flash Family
S29GLxxxM_00_B1_E August 4, 2004
Data she e t
Alternate CE# Controlled Erase and Program Operations-S29GL256M
Notes:
1. Not 100% tested.
2. See the “Erase and Programming Performance” section for more information.
3. For 1–16 words/1–32 bytes programmed.
4. If a program suspend command is issued within tPOLL, the device requires tPOLL before reading status data, once programming has resumed
(that is, the program resume command has been written). If the suspend command was issued after tPOLL, status data is available imme-
diately after programming has resumed. See 24.
Parameter
Speed Options
Unit
JEDEC
Std.
Description
10
11
tAVAV
tWC
Write Cycle Time (Note 1)
Min
100
110
ns
tAVWL
tAS
Address Setup Time
Min
0
ns
tELAX
tAH
Address Hold Time
Min
45
ns
tDVEH
tDS
Data Setup Time
Min
45
ns
tEHDX
tDH
Data Hold Time
Min
0
ns
tGHEL
Read Recovery Time Before Write (OE# High to WE# Low)
Min
0
ns
tWLEL
tWS
WE# Setup Time
Min
0
ns
tEHWH
tWH
WE# Hold Time
Min
0
ns
tELEH
tCP
CE# Pulse Width
Min
35
ns
tEHEL
tCPH
CE# Pulse Width High
Min
25
ns
tWHWH1
Write Buffer Program Operation (Notes 2, 3)
Typ
240
s
Single Word Program Operation (Note 2)
Typ
60
Accelerated Single Word Program Operation (Note 2)
Typ
54
tWHWH2
Sector Erase Operation (Note 2)
Typ
0.5
sec
tRH
RESET# High Time Before Write
Min
50
ns
tPOLL
Program Valid before Status Polling
Max
4
s
