TFP510
TI PanelBus DIGITAL TRANSMITTER
SLDS146B JANUARY 2002 REVISED DECEMBER 2002
20
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
register descriptions (continued)
CFG
Sub-Address = 0B
Read Only
7
6
5
4
3
2
1
0
CFG[7:0] (D[23:16])
This read-only register contains the state of the inputs D[23:16]. These pins can be used to provide the user with
selectable configuration data through the I2C bus.
RESERVED
Sub-Address = 0E0C
Read/Write
Default = 0x97D0A9
7
6
5
4
3
2
1
0
RESERVED
These read/write registers have no effect on TFP510 operation.
DE_DLY
Sub-Address = 32
Read/Write
Default = 0x00
7
6
5
4
3
2
1
0
DE_DLY[7:0]
This read/write register defines the number of pixels after HSYNC goes active that DE is generated, when the DE
generator is enabled.
DE_CTL
Sub-Address = 33
Read/Write
Default = 0x00
7
6
5
4
3
2
1
0
Reserved
DE_GEN
VS_POL
HS_POL
Reserved
DE_DLY[8]
DE_DLY[8]: This read/write register contains the top bit of DE_DLY.
HS_POL: This read/write register sets the HSYNC polarity.
0: HSYNC is considered active low.
1: HSYNC is considered active high.
Pixel counts are reset on the HSYNC active edge.
VS_POL: This read/write register sets the VSYNC polarity.
0: VSYNC is considered active low.
1: VSYNC is considered active high.
Line counts are reset on the VSYNC active edge.
DE_GEN: This read/write register enables the internal DE generator.
0: DE generator is disabled. Signal required on DE pin
1: DE generator is enabled. DE pin is ignored.
DE_TOP
Sub-Address = 34
Read/Write
Default = 0x00
7
6
5
4
3
2
1
0
DE_TOP[7:0]
This read/write register defines the number of pixels after VSYNC goes active that DE is generated, when the DE
generator is enabled.
