www.ti.com
SLAS671 – FEBRUARY 2010
Page 1 / Register 35 (0x23): DAC_L and DAC_R Output Mixer Routing
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7–D6
R/W
00
00: DAC_L is not routed anywhere.
01: DAC_L is routed to the left-channel mixer amplifier.
10: DAC_L is routed directly to the HPL driver.
11: Reserved
D5
R/W
0
0: AIN1 input is not routed to the left-channel mixer amplifier.
1: AIN1 input is routed to the left-channel mixer amplifier.
D4
0
0: AIN2 input is not routed to the left-channel mixer amplifier.
1: AIN2 input is routed to the left-channel mixer amplifier.
D3–D2
R/W
00
00: DAC_R is not routed anywhere.
01: DAC_R is routed to the right-channel mixer amplifier.
10: DAC_R is routed directly to the HPR driver.
11: Reserved
D1
R/W
0
0: AIN2 input is not routed to the right-channel mixer amplifier.
1: AIN2 input is routed to the right-channel mixer amplifier.
D0
R/W
0
0: HPL driver output is not routed to the HPR driver.
1: HPL driver output is routed to the HPR driver input (used for differential output mode).
Page 1 / Register 36 (0x24): Left Analog Vol to HPL
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7
R/W
0
0: Left-channel analog volume control is not routed to HPL output driver.
1: Left-channel analog volume control is routed to HPL output driver.
D6–D0
R/W
111 1111
Left-channel analog volume control gain (non-linear) for the HPL output driver, 0 dB to –78 dB. See
Page 1 / Register 37 (0x25): Right Analog Vol to HPR
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7
R/W
0
0: Right-channel analog volume control is not routed to HPR output driver.
1: Right-channel analog volume control is routed to HPR output driver.
D6–D0
R/W
111 1111
Right-channel analog volume control gain (non-linear) for the HPR output driver, 0 dB to –78 dB. See
Page 1 / Register 38 (0x26): Left Analog Vol to SPK
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7
R/W
0
0: Left-channel analog volume control output is not routed to class-D output driver.
1: Left-channel analog volume control output is routed to class-D output driver.
D6–D0
R/W
111 1111
Left-channel analog volume control output gain (non-linear) for the class-D output driver, 0 dB to –78
dB. See Table 5-24 and Table 5-25.
Page 1 / Register 39 (0x27): Reserved
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7–D0
R
0111 1111
Reserved. Do not use.
Copyright 2010, Texas Instruments Incorporated
REGISTER MAP
77
Product Folder Link(s): TLV320DAC3100
