SLOS641A – JUNE 2009 – REVISED OCTOBER 2009 ..................................................................................................................................................... www.ti.com
BIT
7
6
5
4
3
2
1
0
Function
Mode[2]
Mode[1]
Mode[0]
MON_Vol[4]
MON_Vol[3]
MON_Vol[2]
MON_Vol[1]
MON_Vol[0]
Reset Value
0
1
0
1
Mode[2:0]
Sets mux output mode. Refer to Modes of Operation section for details. Default mode is 000
(Mono Input selected) on power-up.
MON_Vol[4:0] Five-bit volume control for Mono input mode (mode 0). 11111 sets device to its highest channel
gain; 00000 sets device to its lowest channel gain. Default setting on power-up is 01101 (0 dB).
Stereo Input 1 / Output Gain Control Register (Address: 5)
BIT
7
6
5
4
3
2
1
0
Function
SPK_Gain
HP_0dB
Reserved
ST1_Vol[4]
ST1_Vol[3]
ST1_Vol[2]
ST1_Vol[1]
ST1_Vol[0]
Reset Value
0
1
0
1
SPK_Gain
Class-D speaker amplifier gain. Set to logic high for 12 dB Class-D gain. Set to logic low for
6 dB Class-D gain.
HP_0dB
Set bit to 1 to set HP amp gain to 0 dB regardless of HP_Gain[2:0] setting. The default is 0.
Reserved
These bits are reserved for future enhancements. Do not write to these bits as writing to these
bits may change device function. If read these bits may assume any value.
ST1_Vol[4:0]
Five-bit volume control for Stereo Input 1 (modes 1, 3, 5, and 6): INL1 and INR1. 11111 sets
device to its highest gain; 00000 sets device to its lowest gain. Default setting on power-up is
01101 (0 dB).
Stereo Input 2 / Headphone Gain Control Register (Addresses: 6)
BIT
7
6
5
4
3
2
1
0
Function
HP_Gain[2]
HP_Gain1]
HP_Gain[0]
ST2_Vol[4]
ST2_Vol[3]
ST2_Vol[2]
ST2_Vol[1]
ST2_Vol[0]
Reset Value
0
1
0
1
HP_Gain [2:0] Headphone gain select. Sets the gain of the headphone output amplifiers according to Table 2.
The default is 000.
ST2_Vol[4:0]
Five-bit volume control for Stereo Input 2 (modes 2 and 4): INL2 and INR2. 11111 sets device
to its highest gain; 00000 sets device to its lowest gain. Default setting on power-up is 01101
(0 dB).
18
Copyright 2009, Texas Instruments Incorporated
Product Folder Link(s): TPA2051D3
