2004 Aug 25
82
Philips Semiconductors
Product specication
Multimedia bridge, high performance
Scaler and PCI circuit (SPCI)
SAA7146A
58
BXO
16 to 7
RW
horizontal offset, counted in
qualied LLC cycles, after
selected horizontal sync edge, till
data is captured from DD1
BXO denes a horizontal offset,
counted in LLC cycles, after
selected horizontal sync edge till
data is read from the FIFO
in eld memory mode the
following offsets depending on the
horizontal scaling ratio must be
selected to guarantee the correct
outrun behaviour of the scaler
(see Table 70). The video window
is select by ‘NumLines’,
‘NumBytes’, ‘pitch’ and ‘base
address’
BRS_H
6 to 4
RW
horizontal downscaling
(see Section 7.10.1):
horizontal upscaling:
000: every pixel is captured
000: provide every sample once
001: every 2nd pixel is captured
001: provide every sample
twice
010: reserved
011: every 4th pixel is captured
011: provide every sample
4 times
100: reserved
101: reserved
110: reserved
111: every 8th pixel is captured
111: provide every sample
8 times
Read mode
3 and 2
RW
reserved
00: line memory mode
01: field memory mode
10: direct mode with pixel
repetition for not qualified bytes.
11: direct with grey pixel (10H
for luminance and 80H for
chrominance values) for not
qualified bytes.
PCI format
1 and 0
RW
output format PCI side:
input format PCI side:
00: YUV4:2:2
01: Y8, only luminance
01: reserved
10: Y2, 2 MSBs of Y only
10: reserved
11: Y1, 1 MSB of Y only
11: reserved
OFFSET
(HEX)
NAME
BIT
TYPE
DESCRIPTION
INBOUND
OUTBOUND
