AD8370
ABSOLUTE MAXIMUM RATINGS
Table 2.
Parameter
Supply Voltage, V
S
PWUP, DATA, CLCK, LTCH
Differential Input Voltage,
V
INHI
– V
INLO
Common-Mode Input Voltage, V
INHI
or
V
INLO,
with respect to ICOM or OCOM
Rev. 0 | Page 5 of 28
Rating
5.5 V
V
S
+ 500 mV
2 V
V
S
+ 500 mV
(maximum),
V
ICOM
– 500 mV,
V
OCOM
– 500 mV
(minimum)
575 mW
30°C/W
95°C/W
9°C/W
150°C
–40°C to +85°C
–65°C to +150°C
235°C
Internal Power Dissipation
θ
JA
(Exposed paddle soldered down)
θ
JA
(Exposed paddle not soldered down)
θ
JC
(At exposed paddle)
Maximum Junction Temperature
Operating Temperature Range
Storage Temperature Range
Lead Temperature Range
(Soldering 60 sec)
Stresses above those listed under Absolute Maximum
Ratings may cause permanent damage to the device.
This is a stress rating only; functional operation of the
device at these or any other conditions above those
listed in the operational sections of this specification
is not implied. Exposure to absolute maximum rating
conditions for extended periods may affect device
reliability.
ESD CAUTION
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily accumulate on the
human body and test equipment and can discharge without detection. Although this product features
proprietary ESD protection circuitry, permanent damage may occur on devices subjected to high energy
electrostatic discharges. Therefore, proper ESD precautions are recommended to avoid performance
degradation or loss of functionality.
