REV. A
AD9876
–5–
CAUTION
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily
accumulate on the human body and test equipment and can discharge without detection. Although
the AD9876 features proprietary ESD protection circuitry, permanent damage may occur on
devices subjected to high energy electrostatic discharges. Therefore, proper ESD precautions are
recommended to avoid performance degradation or loss of functionality.
WARNING!
ESD SENSITIVE DEVICE
ABSOLUTE MAXIMUM RATINGS
*
Power Supply (V
S
) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.9 V
Digital Output Current . . . . . . . . . . . . . . . . . . . . . . . . . 5 mA
Digital Inputs . . . . . . . . . . . . . . . –0.3 V to DRVDD + 0.3 V
Analog Inputs . . . . . . . . . . . . . . . . . –0.3 V to AVDD + 0.3 V
Operating Temperature . . . . . . . . . . . . . . . . . –40
°
C to +85
°
C
Maximum Junction Temperature . . . . . . . . . . . . . . . . 150
°
C
Storage Temperature . . . . . . . . . . . . . . . . . . –65
°
C to +150
°
C
Lead Temperature (Soldering 10 sec) . . . . . . . . . . . . . 300
°
C
*
Stresses greater than those listed under Absolute Maximum Ratings may cause
permanent damage to the device. This is a stress rating only; functional operation
of the device at these or any other conditions above those indicated in the
operational section of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect device reliability.
EXPLANATION OF TEST LEVELS
I
– Devices are 100% production tested at 25
°
C and guaran-
teed by design and characterization testing for industrial
operating temperature range (–40
°
C to +85
°
C).
II – Parameter is guaranteed by design and/or characteriza-
tion testing.
III – Parameter is a typical value only.
THERMAL CHARACTERISTICS
Thermal Resistance
48-Lead LQFP
JA
= 57
°
C/W
JC
= 28
°
C/W
Model
AD9876BST
AD9876-EB
AD9876BSTRL
Temperature Range
–40
°
C to +85
°
C
–40
°
C to +85
°
C
–40
°
C to +85
°
C
Package Description
48-Lead LQFP
Evaluation Board
BST Reel
Package Option
ST-48
ORDERING GUIDE
