參數資料
| 型號： | AP4503BGM-HF |
| 廠商： | ADVANCED POWER ELECTRONICS CORP |
| 元件分類： | JFETs |
| 英文描述： | 8.2 A, 30 V, 0.018 ohm, 2 CHANNEL, N AND P-CHANNEL, Si, POWER, MOSFET |
| 封裝： | HALOGEN FREE AND ROHS COMPLIANT, SOP-8 |
| 文件頁數： | 2/7頁 |
| 文件大?。?/td> | 118K |
| 代理商： | AP4503BGM-HF |
N-CH Electrical Characteristics@Tj=25
oC(unless otherwise specified)
Symbol
Parameter
Test Conditions
Min.
Typ. Max. Units
BVDSS
Drain-Source Breakdown Voltage
VGS=0V, ID=250uA
30
-
V
RDS(ON)
Static Drain-Source On-Resistance
2
VGS=10V, ID=8A
-
18
m
VGS=4.5V, ID=5A
-
35
m
VGS(th)
Gate Threshold Voltage
VDS=VGS, ID=250uA
1
-
3
V
gfs
Forward Transconductance
VDS=10V, ID=8A
-
14
-
S
IDSS
Drain-Source Leakage Current
VDS=30V, VGS=0V
-
1
uA
IGSS
Gate-Source Leakage
VGS=+20V, VDS=0V
-
+100
nA
Qg
Total Gate Charge
2
ID=8A
-
6
9.6
nC
Qgs
Gate-Source Charge
VDS=15V
-
1.5
-
nC
Qgd
Gate-Drain ("Miller") Charge
VGS=4.5V
-
3.5
-
nC
td(on)
Turn-on Delay Time
2
VDS=15V
-
6
-
ns
tr
Rise Time
ID=1A
-
7
-
ns
td(off)
Turn-off Delay Time
RG=3.3Ω,VGS=10V
-
15
-
ns
tf
Fall Time
RD=15Ω
-
3.5
-
ns
Ciss
Input Capacitance
VGS=0V
-
370
590
pF
Coss
Output Capacitance
VDS=25V
-
90
-
pF
Crss
Reverse Transfer Capacitance
f=1.0MHz
-
75
-
pF
Rg
Gate Resistance
f=1.0MHz
-
1.5
-
Source-Drain Diode
Symbol
Parameter
Test Conditions
Min.
Typ. Max. Units
VSD
Forward On Voltage
2
IS=1.7A, VGS=0V
-
1.2
V
trr
Reverse Recovery Time
2
IS=8A, VGS=0V,
-
18
-
ns
Qrr
Reverse Recovery Charge
dI/dt=100A/s
-
9
-
nC
2
AP4503BGM-HF
