Philips Semiconductors
P89LPC930/931
8-bit microcontrollers with two-clock 80C51 core
Product data
Rev. 03 — 06 October 2003
7 of 54
9397 750 12122
Koninklijke Philips Electronics N.V. 2003. All rights reserved.
P1.0 - P1.7
18, 17, 12,
11, 10, 6,
5, 4
I/O, I
[1]
Port 1:
Port 1 is an 8-bit I/O port with a user-configurable output type, except for
three pins as noted below. During reset Port 1 latches are configured in the input only
mode with the internal pull-up disabled. The operation of the configurable Port 1 pins
as inputs and outputs depends upon the port configuration selected. Each of the
configurable port pins are programmed independently. Refer to
Section 8.11.1 “Port
configurations”
and
Table 7 “DC electrical characteristics”
for details. P1.2 - P1.3 are
open drain when used as outputs. P1.5 is input only.
All pins have Schmitt triggered inputs.
Port 1 also provides various special functions as described below:
P1.0 —
Port 1 bit 0.
TxD —
Transmitter output for the serial port.
P1.1 —
Port 1 bit 1.
RXD —
Receiver input for the serial port.
P1.2 —
Port 1 bit 2 (open-drain when used as output).
T0 —
Timer/counter 0 external count input or overflow output (open-drain when used
as output).
SCL —
I
2
C serial clock input/output.
P1.3 —
Port 1 bit 3 (open-drain when used as output).
INT0 —
External interrupt 0 input.
SDA —
I
2
C serial data input/output.
P1.4 —
Port 1 bit 4.
INT1 —
External interrupt 1 input.
P1.5 —
Port 1 bit 5 (input only).
RST —
External Reset input during Power-on or if selected via UCFG1. When
functioning as a reset input a LOW on this pin resets the microcontroller, causing I/O
ports and peripherals to take on their default states, and the processor begins
execution at address 0. Also used during a power-on sequence to force In-System
Programming mode.
P1.6 —
Port 1 bit 6.
P1.7 —
Port 1 bit 7.
18
I/O
O
I/O
I
I/O
I/O
17
12
I/O
I
I
I/O
I
I
I
I
11
10
6
5
4
I/O
I/O
Table 3:
Symbol
Pin description
…continued
Pin
Type
Description
