Philips Semiconductors
P89LPC930/931
8-bit microcontrollers with two-clock 80C51 core
Product data
Rev. 03 — 06 October 2003
8 of 54
9397 750 12122
Koninklijke Philips Electronics N.V. 2003. All rights reserved.
P2.0 - P2.7
1, 2, 13,
14, 15, 16,
27, 28
I/O
Port 2:
Port 2 is a 8-bit I/O port with a user-configurable output type. During reset
Port 2 latches are configured in the input only mode with the internal pull-up disabled.
The operation of port 2 pins as inputs and outputs depends upon the port
configuration selected. Each port pin is configured independently. Refer to the
section on I/O port configuration and the DC Electrical Characteristics for details.
This port is not available in 20-pin package and is configured automatically as
outputs to conserve power. The alternate functions for these pins must not be
enabled.
All pins have Schmitt triggered inputs.
Port 2 also provides various special functions as described below.
P2.0 —
Port 2 bit 0.
P2.1 —
Port 2 bit 1.
P2.2 —
Port 2 bit 2.
MOSI —
SPI master out slave in. When configured as master, this pin is output,
when configured as slave, this pin is input.
P2.3 —
Port 2 bit 3.
MISO —
SPI master in slave out. When configured as master, this pin is input, when
configured as slave, this pin is output.
P2.4 —
Port 2 bit 4.
SS —
SPI Slave select.
P2.5 —
Port 2 bit 5.
SPICLK —
SPI clock. When configured as master, this pin is output, when
configured as slave, this pin is input.
P2.6 —
Port 2 bit 6.
P2.7 —
Port 2 bit 7.
1
2
13
I/O
I/O
I/O
I/O
14
I/O
I/O
15
I/O
I
I/O
I/O
16
27
28
I/O
I/O
Table 3:
Symbol
Pin description
…continued
Pin
Type
Description
