17
8
7
16
10
BST
SW
PGND
VOUT
VIN
EN
COMP
VREF
TPS51317
9
20
REFIN
V5IN
19
18
6
PGOOD
MODE
GND
PGOOD
V
OUT
PGND
GND
5VIN
UDG-11041
VIN
PGND GND
GND
SLUSAH9
– MARCH 2011
3.3-V/5-V Input, 6-A, D-CAP+
Mode Synchronous Step-Down Integrated FETs Converter
Check for Samples: TPS51317
1
FEATURES
DESCRIPTION
The TPS51317 is a fully integrated synchronous buck
2
Integrated FETs Converter w/TI Proprietary
regulator employing D-CAP+
mode architechture. It
D-CAP+
Mode Architecture
is used for 3.3-V and 5-V step-down systems where
Minimum External Components Count
space is a consideration, high-performance and
Support all MLCC Output Capacitor and
optimized
component
count
are
required.
The
TPS51317 features four switching frequency settings
SP/POSCAP
(up to 1.5 MHz), synchronous operation in SKIP,
Auto-Skip Mode and Ripple Reduction Mode
droop support, external tracking support, pre-bias
Optimized Efficiency at Light and Heavy Loads
startup, output soft discharge, integrated bootstrap
Selectable 800-kHz, 1-MHz, 1.2-MHz and
switch, power good function, enable function and
complete
protection
functions,
and
both
output
1.5-MHz Frequency
ceramic and SP/POS capacitor support. It supports
Up to 6.0-V Conversion Voltage Range
supply and conversion voltages up to 6.0 V, and
Adjustable Output Voltage Range From 0.6 V
output voltages adjustable from 0.6 V to 2.0V. The
to 2 V
TPS51317 is available in the 3.5 mm
× 4 mm 20-pin
QFN package (Green RoHs compliant and Pb free)
Small 3.5 mm
× 4 mm, 20-Pin QFN Package
and is specified from -40
°C to 85°C.
APPLICATIONS
Low-Voltage Applications Stepping Down from
5-V or 3.3-V Rail
XXXX
1
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas
Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
2
D-CAP+ is a trademark of Texas Instruments.
PRODUCTION DATA information is current as of publication date.
Copyright
2011, Texas Instruments Incorporated
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
